ASUS ROG -THOR-1600T3-GAMING power supply unit 1600 W 20+4 pin ATX ATX Grey
ASUS ROG -THOR-1600T3-GAMING, 1600 W, 100 - 240 V, Active, 125 W, 1600 W, 125 W
Availability: In Stock
ULTIMATE POWER. UNMATCHED STABILITY.The ROG Thor 1600W Titanium III delivers the ultimate power and stability demanded by gamers. A next-gen GaN MOSFET delivers superior efficiency, and "GPU-First" voltage sensing features a patented-intelligent voltage stabilizer, ensuring top-tier performance and stability. Meanwhile, there is Turbo Mode for maximum cooling when overclocking or for other demanding workloads.The ROG Thor 1600W Titanium III also features the signature Thor OLED display, now upgraded for easy magnetic attachment - it can be swapped to either side of the unit to accommodate fan-up or fan-down PSU installation.
| Power | |
|---|---|
| Total power | 1600 W |
| AC input voltage | 100 - 240 V |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 125 W |
| Combined power (+12V) | 1600 W |
| Combined power (+5V) | 125 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 30 A |
| Max output current (+12V) | 133.3 A |
| Max output current (+5V) | 25 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 610 mm |
| Number of SATA power connectors | 10 |
| SATA power cable length | 120,400 mm |
| Peripheral (Molex) power connectors (4-pin) | 9 |
| Peripheral (Molex) power cable length | 150,400 mm |
| PCI Express power connectors (6+2 pin) | 4 |
| PCI Express power connectors (16-pin) | 2 |
| PCI Express power cable length | 750 mm |
| CPU power connector (4+4 pin) | Y |
| CPU power cable length | 1000 mm |
| Cabling type | Fully-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Titanium |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Silent mode | Y |
| Bearing technology | DBB |
| Mean time between failures (MTBF) | 120000 h |
| Design | |
| Product colour | Grey |
| Cooling type | Active |
| Number of fans | 1 fan(s) |
| Illumination | Y |
| Built-in display | Y |
| Display type | OLED |
| On/off switch | Y |
| Packaging content | |
| Cables included | CPU,PCIe,Peripheral (Molex),SATA |
| Cable tie(s) included | Y |
| Weight & dimensions | |
| Width | 200 mm |
| Depth | 150 mm |
| Height | 86 mm |
| Weight | 2800 g |
| Packaging data | |
| Package width | 390 mm |
| Package depth | 251 mm |
| Package height | 159 mm |
| Package weight | 6300 g |
| Package type | Box |
