ATEN 2-Port USB 3.1 Gen 1 4K DisplayPort 1.2 KVMP™ Switch with Audio (KVM cables included)
ATEN 2-Port USB 3.1 Gen 1 4K DisplayPort 1.2 KVMP™ Switch with Audio (KVM cables included), 4096 x 2160 pixels, 4K Ultra HD, 2 W, Black
Availability: Arriving Soon
The ATEN CS1922 2-Port USB 3.0 4K DisplayPort KVMP™ Switch provides the latest innovations in desktop KVM switching technology for the increasing demand of higher video quality and transfer speeds on modern computers. The ATEN CS1922 offers an unprecedented performance of delivering 4K resolution, the next generation USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates and enhanced user-friendly operations.1x CS1922 2-Port USB 3.0 4K DisplayPort KVMP™ Switch2x LIN5-20K1-K13G DisplayPort Cables2x LIN6-11C1-E12G USB 3.0 Cables2x LIN5-0205-21CG Audio Cable2x LIN5-0205-21DG Audio Cable1x 0AD8-8005-40MG Power Adapter1x LIN2-418K-E12G Power Cord1x User Instructions
| Ports & interfaces | |
|---|---|
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DisplayPorts quantity | 3 |
| Console ports | 3.5mm mic,DisplayPort,USB B |
| Console USB ports quantity | 2 |
| USB hub | Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
| USB connector type | USB Type-B |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Audio connections | Y |
| Headphone outputs | 4 |
| Number of microphone inputs | 4 |
| DC-in jack | Y |
| Performance | |
| HD type | 4K Ultra HD |
| Maximum resolution | 4096 x 2160 pixels |
| Scan interval | 1,99 s |
| HDCP | Y |
| Hot-Plug support | Y |
| Design | |
| Product colour | Black |
| Housing material | Metal,Plastic |
| LED indicators | Operation,USB |
| Push button | Y |
| Display | |
| Built-in display | N |
| Power | |
| Power source | DC |
| Output voltage | 5 V |
| Power consumption (typical) | 2 W |
| External power adapter | Y |
| System requirements | |
| Windows operating systems supported | Y |
| Linux operating systems supported | Y |
| Mac operating systems supported | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Weight & dimensions | |
| Width | 88 mm |
| Depth | 210 mm |
| Height | 55.5 mm |
| Weight | 1420 g |
| Packaging data | |
| Package width | 100 mm |
| Package depth | 283 mm |
| Package height | 173 mm |
| Package weight | 1865 g |
| Packaging content | |
| Cables included | Audio (3.5mm),DisplayPort,USB |
| Manual | Y |
| AC adapter included | Y |
| Logistics data | |
| Master (outer) case net weight | 7100 g |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 292 mm |
| Master (outer) case length | 517 mm |
| Master (outer) case height | 194 mm |
| Master (outer) case gross weight | 9800 g |
| Products per master (outer) case | 5 pc(s) |
