Zyxel SFP10G-SR-E network transceiver module Fiber optic 10000 Mbit/s SFP+ 850 nm
(0 review)Add your review
€366,33

Zyxel SFP10G-SR-E, Fiber optic, 10000 Mbit/s, SFP+, LC, 300 m, 850 nm

Availability: Arriving Soon
EAN:4718937619238Categories:NetworkingTags:

Hot-pluggable with maximum flexibilityIndependent transceiver design provides the highest network maintenance flexibility. Transceivers can be freely added when required, and infrastructure upgrades or transceiver repairs can be done easily by just replacing the transceiver instead of the whole device.No extra cabling cost to upgrade the fiber plantTraditional fiber optic networking requires two strands of fiber for sending and receiving signals to accomplish communications.The bi-directional, dual-wavelength transceivers can establish communications over just one strand of fiber. Transmission capacity can be expanded immediately without additional cost laying new fiber.Supports digital diagnostics monitoring interface (DDMI)DDMI enables the switch to access operating parameters within the fiber link. This includes digital features such as soft control and monitoring of SFP I/O signals. In addition, the DDMI functionality enables the capability to implement digital alarms and warnings.Complete fiber accessory portfolioWe provide multiple options including 1G SFP, 10G SFP+ and 10G DAC cables for different installation requirements.

Performance
SFP transceiver typeFiber optic
Maximum data transfer rate10000 Mbit/s
Interface typeSFP+
Multi-mode fiber (MMF) supportedY
Fiber optic connectorLC
Maximum transfer distance300 m
Wavelength850 nm
Tx power (min)-1 dBmW
Tx power (max)-8.2 dBmW
Rx power (min)0 dBmW
Rx power (max)-11.1 dBmW
Features
Product colourSteel
Brand compatibilityZyxel
Power
Input voltage3.14-3.46 V
Maximum current0.3 A
Weight & dimensions
Width14.8 mm
Depth56.5 mm
Height11.85 mm
Weight20 g
Logistics data
Harmonized System (HS) code85369010
Country of originChina
