NETGEAR 8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Plus Switch Managed L2/L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) Grey
NETGEAR 8-port Ultra60 PoE++ Multi-Gigabit (2.5G) Ethernet Plus Switch, Managed, L2/L3, 2.5G Ethernet (100/1000/2500), Full duplex, Power over Ethernet (PoE)
Availability: Arriving Soon
Provides 8 ports 1G/2.5G with 4 PoE+ ports and 4 Ultra60 PoE++ ports making it a perfect switch for WiFi 6 AP connectivity, IP surveillance and more.Multi-Gigabit Ethernet8 ports provide up to 2.5 Gbps of dedicated, non-blocking bandwidth each.PoE Support4 Ultra60 PoE++ and 4 PoE+ ports provide a total of 230W of power so you can power and connect your devices with a single wire.Advanced PoE ControlsManage PoE prioritization, scheduling, power limit per port, and more for simple control over all PoE-powered devices.Non-Blocking Switching40Gbps (10/100/1000 Mbps) line rate fabric ensures congestion-free connectivity to your devices.Fanless DesignSilent operation makes this switch perfect for noise-sensitive environments.Versatile Mounting OptionsInstall your switch on your desktop, or mount it to your wall or rack with the hardware provided in the box.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Network | |
| Networking standards | IEEE 802.1Q,IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3bt,IEEE 802.3u,IEEE 802.3x |
| 10G support | N |
| Copper ethernet cabling technology | 100BASE-T,1000BASE-T |
| Port mirroring | Y |
| Full duplex | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Rate limiting | Y |
| VLAN support | Y |
| Virtual LAN features | Port-based VLAN,Tagged VLAN |
| Number of VLANs | 64 |
| Data transmission | |
| Switching capacity | 40 Gbit/s |
| MAC address table | 16000 entries |
| Store-and-forward | Y |
| Jumbo frames support | Y |
| Jumbo frames | 12000 |
| Packet buffer memory | 1.5 MB |
| Security | |
| DHCP features | DHCP client |
| IGMP snooping | Y |
| Password protection | Y |
| Queue scheduling algorithms | Strict Priority Queue (SPQ),Weighted Round Robin (WRR) |
| Multicast features | |
| Multicast support | Y |
| Number of multicast groups filtered | 128 |
| Design | |
| Rack mounting | N |
| Stackable | N |
| Product colour | Grey |
| Housing material | Metal |
| LED indicators | Y |
| Performance | |
| Mean time between failures (MTBF) | 373644 h |
| Power | |
| Power source | PoE |
| Power supply included | Y |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 230 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 3000 m |
| Weight & dimensions | |
| Width | 210 mm |
| Depth | 140 mm |
| Height | 40 mm |
| Weight | 900 g |
| Certificates | |
| Certification | CE FCC 15 B CE/EN55032/24 CSA VCCI ACMA KC CCC BSMI |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
