TP-Link Omada 28-Port Gigabit L2+ Managed Switch with 24-Port PoE+

€364,65

TP-Link Omada 28-Port Gigabit L2+ Managed Switch with 24-Port PoE+, Managed, L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U

Availability: In Stock

Add to Cart

Add to wishlist

Compare

EAN:6935364010737Categories:NetworkingTags:

TP-Link | Omada L2+ managed switches provide high performance, powerful L2 and L2+ features like staticrouting, enterprise-level QoS, advanced security strategies and a bundle of ISP features. The IP-MAC-PortBinding (IMPB) and Access Control List (ACL) functions protect against broadcast storm, ARP and Denial-ofService (DoS) attacks, etc. Quality of Service (QoS, L2 to L4) provides enhanced traffic management capabilities to move your data smoother and faster. The OAM and DDM functions help facilitate network management. Moreover, the easy-to-use web management interfaces, along with CLI, SNMP and Dual Image mean faster setup and configuration with less downtime. TP-Link | Omada L2+ managed Switches provide a reliable, secure solution for enterprise, campus and ISP networks.

Management features
Switch type	Managed
Switch layer	L2+
Quality of Service (QoS) support	Y
Web-based management	Y
Cloud-managed	Y
ARP inspection	Y
Configuring Location Settings (CLI)	Y
System event log	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	24
SFP module slots quantity	4
Console port	RJ-45/Micro-USB
Power connector	AC-in jack
Network
Networking standards	IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3z
10G support	N
Copper ethernet cabling technology	10BASE-T,1000BASE-T
Port mirroring	Y
IP routing	Y
Flow control support	Y
Link aggregation	Y
Broadcast storm control	Y
Rate limiting	Y
Spanning tree protocol	Y
Head-of-line (HOL) blocking	Y
Ethernet LAN data rates	10,100,1000 Mbit/s
Active link detection	Y
VLAN support	Y
Virtual LAN features	MAC address-based VLAN,Port-based VLAN,Private VLAN,Tagged VLAN,Voice VLAN
Number of VLANs	4000
Data transmission
Switching capacity	56 Gbit/s
Forwarding rate	41.66 Mpps
MAC address table	16000 entries
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	12 MB
Security
DHCP features	DHCP client,DHCP relay,DHCP server,DHCP snooping,DHCPv6 client,DHCPv6 snooping
Access Control List (ACL)	Y
IGMP snooping	Y
Security algorithms	SSH,SSL/TLS
MAC address filtering	Y
Static port security	Y
SSH/SSL support	Y
Loop protection	Y
BPDU filtering/protection	Y
IP-MAC-Port binding	Y
Authentication	MAC-based authentication,Port-based authentication
Multicast features
Multicast support	Y
Protocols
Management protocols	SNMPv1/v2c/v3, LLDP/LLDP-MED
GARP VLAN Registration Protocol (GVRP)	Y
Design
Rack mounting	Y
Form factor	1U
Product colour	Black
LED indicators	Y
Number of fans	2 fan(s)
Performance
Export Control Classification Number (ECCN)	EAR99
Power
Power source	AC
Power supply included	Y
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	480.1 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	24
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	384 W
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Heat dissipation	1637.14 BTU/h
Weight & dimensions
Width	440 mm
Depth	330 mm
Height	44 mm
Packaging content
Quick start guide	Y
User guide	Y
Certificates
Certification	CE, FCC, RoHS
