NETGEAR M4250-40G8XF-PoE++ Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 2U Black
NETGEAR M4250-40G8XF-PoE++, Managed, L2/L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 2U
Availability: In Stock
Pre-configured for out-of-the-box useNETGEAR IGMP Plus™ enables instant multicast functionality for most AV over IP installationsDedicated AV web-based GUI interfaceUnique interface designed for the AV professional with color-coded, port-based profilesProfiles for common audio protocolsQuickly assign profiles to ports for Dante, AES67, and AVB audio configurations. AVB Requires a separate licenseVideo profiles built-inSpecial profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as neededUnique Automatic ConfigurationAuto-trunk and auto-lag functionality automatically configures other M4250 switches for use in star topology.Easier configuration with new AV GUIThe AV-oriented, web-based GUI permits factory or user-specified profiles to be assigned to individual ports as needed.Use in noise-sensitive environmentsAdjustable fans can be turned off if certain conditions are met. Even the default Quiet mode is quieter than most other switches.Get up and running fast with little engineering time requiredOur NETGEAR IGMP PlusTM feature is set from the factory to ensure out-of-the-box functionality for most AV over IP installationsMultiple mounting options provide ultimate flexibilityThreaded mounting holes sized to industry standards are built into the chassis for mounting behind a display or clamped to a truss.M4250 AV Line SwitchesAn entirely new series of switches developed and engineered for the growing AV over IP market.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L3 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 40 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 8 |
| USB 2.0 ports quantity | 1 |
| Network | |
| Networking standards | IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt |
| 10G support | Y |
| Data transmission | |
| Switching capacity | 240 Gbit/s |
| Throughput | 178.56 Mpps |
| MAC address table | 16000 entries |
| Latency (1 Gbps) | 2.78 µs |
| Latency (10 Gbps) | 0.73 µs |
| Jumbo frames support | Y |
| Design | |
| Rack mounting | Y |
| Form factor | 2U |
| Product colour | Black |
| Performance | |
| Noise level | 60 dB |
| Fanless | Y |
| Power | |
| Power supply included | Y |
| Power consumption (typical) | 912 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) type supported | Active PoE |
| Power over Ethernet plus (PoE+) ports quantity | 40 |
| Total Power over Ethernet (PoE) budget | 2880 W |
| Operational conditions | |
| Heat dissipation | 3113.57 BTU/h |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 86.4 mm |
| Height | 350 mm |
| Weight | 10280 g |
| Packaging content | |
| Cables included | LAN (RJ-45),USB Type-C |
| User guide | Y |
| Rack mount kit | Y |
| Packaging data | |
| Rack rails | Y |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
