TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+

€115,97

TP-Link 16-Port Gigabit Easy Smart Switch with 8-Port PoE+, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:6935364098865Categories:Networking

What This Product DoesThe TL-SG1016PE is an 16-Port Gigabit Desktop/Rack mountable Switch with 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 110W, up to 30W per port, TL-SG1016PE can power more high-powered devices such as wireless Access Points (APs), IP Cameras or IP Phones. Moreover, with innovative energy-efficient technology, the TL-SG1016PE can save up to 75% of the power consumption, making it an eco-friendly solution for your business network.

Management features
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	16
Power connector	AC-in jack
Network
Networking standards	IEEE 802.1Q,IEEE 802.1p,IEEE 802.3ab,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x
10G support	N
Copper ethernet cabling technology	10BASE-T,100BASE-TX,1000BASE-T
Cable types supported	Cat3,Cat4,Cat5,Cat5e,Cat6
Port mirroring	Y
Flow control support	Y
Link aggregation	Y
Broadcast storm control	Y
Auto MDI/MDI-X	Y
Auto-negotiation	Y
VLAN support	Y
Virtual LAN features	Tagged VLAN,Port-based VLAN
Number of VLANs	4000
Data transmission
Switching capacity	32 Gbit/s
Forwarding rate	23.8 Mpps
MAC address table	8000 entries
Store-and-forward	Y
Number of queues	4
Jumbo frames support	Y
Jumbo frames	10000
Packet buffer memory	4.1 MB
Security
IGMP snooping	Y
Design
Rack mounting	Y
Stackable	N
Form factor	1U
Product colour	Black
Housing material	Metal
LED indicators	Y
Number of fans	1 fan(s)
Performance
Compatible operating systems	Windows
Maximum cable length	100 m
Power
Power source	AC/PoE
Power supply included	Y
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	124.4 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	8
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	110 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Weight & dimensions
Width	294 mm
Depth	180 mm
Height	44 mm
Packaging content
Cables included	AC
User guide	Y
Rack mount kit	Y
Packaging data
Package type	Box
Resource CD	Y
Package width	250 mm
Package depth	400 mm
Package height	80 mm
Package weight	2280 g
Sustainability
Sustainability compliance	Y
Certificates
Compliance certificates	CE,Federal Communications Commission (FCC),RoHS
