Lenovo ThinkStation P5 Intel Xeon W w5-2445 32 GB DDR5-SDRAM 1 TB SSD Windows 11 Pro for Workstations Tower Workstation Black, Red
Lenovo ThinkStation P5, 3.1 GHz, Intel Xeon W, w5-2445, 32 GB, 1 TB, Windows 11 Pro for Workstations
Availability:: Arriving soon
The next-gen workstation has arrivedEngineered for ultimate productivity and versatility, the Lenovo ThinkStation P5 is the all-around industry workhorse for professionals that demand a scalable, future-proof workstation. Optimized for designers, engineers, and creatives alike, it can support a broad range of compute-intensive tasks with ease, including BIM, complex 3D CAD, VFX, and edge deployments.Extraordinary performance, power, & speedWith its Aston Martin-inspired chassis design and advanced thermals, the ThinkStation P5 workstation is designed to achieve groundbreaking performance. Key features include the latest Intel® Xeon® W processors, delivering a breakthrough new compute architecture, and support for up to two optional NVIDIA® RTX™ graphics cards, offering unprecedented rendering and AI performance. The result? Enough punch for any workflow, even in mission-critical environments.Tried, tested, & trueThe ThinkStation P5 workstation has been proven to meet Lenovo's exacting reliability and durability standards, ensuring that your systems leverage maximum uptime. It also boasts an array of independent software vendor (ISV) certifications, so compute-intensive applications, such as Adobe® and PTC®, are tuned to run seamlessly on even the most complex of tasks.See the complete list of ISV certifications.A future-proof machineWith high-speed DDR5 memory and ultra-fast PCIe storage, the ThinkStation P5 workstation is designed to improve your productivity. It also has the convenience of front drive access, hot-swap storage, tool-less chassis access, and an array of high-performance configurations. As a result, you can enjoy the flexibility of customizing your P5 to tackle your workload needs of today, knowing you can easily upgrade for the ever-increasing datasets of tomorrow.One less thing to worry aboutThe ThinkStation P5 comes with ThinkShield—a suite of essential hardware and software security solutions that work together to protect your workstation and data. Trusted Platform Module (TPM) encrypts your data, while ensuring that your machine has not been tampered with. There are also various programs to prevent unauthorized access to the BIOS—and even self-heal the BIOS should it become corrupted or is maliciously attacked.
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon W |
| Processor model | w5-2445 |
| Processor cores | 10 |
| Processor threads | 20 |
| Processor boost frequency | 4.6 GHz |
| Processor frequency | 3.1 GHz |
| Performance cores | 10 |
| Processor cache | 26.25 MB |
| Processor cache type | Smart Cache |
| Number of processors installed | 1 |
| Processor base power | 175 W |
| Maximum turbo power | 210 W |
| Memory | |
| Internal memory | 32 GB |
| Maximum internal memory | 512 GB |
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 1 x 32 GB |
| Memory slots | 8x DIMM |
| Memory clock speed | 4800 MHz |
| ECC | Y |
| Storage | |
| Total storage capacity | 1000 GB |
| Storage media | SSD |
| Optical drive type | N |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 1000 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 1000 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Y |
| SSD form factor | M.2 |
| Card reader integrated | Y |
| Graphics | |
| Discrete graphics card | N |
| On-board graphics card | N |
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 1000,100 Mbit/s |
| LAN controller | Intel I219-LM |
| Wi-Fi | N |
| Ports & interfaces | |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Line-out | Y |
| Line-in | Y |
| Combo headphone/mic port | Y |
| Expansion slots | |
| PCI Express x4 (Gen 4.x) slots | 3 |
| PCI Express x8 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 2 |
| Design | |
| Chassis type | Tower |
| Volume | 33 L |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Y |
| Cable lock slot type | Kensington |
| Product colour | Black,Red |
| Performance | |
| Market positioning | Business |
| Motherboard chipset | Intel W790 |
| Audio chip | Realtek ALC897-Q |
| Audio system | High Definition Audio |
| Built-in speaker(s) | Y |
| Number of speakers | 1 |
| Password protection | Y |
| Password protection type | Power on,Supervisor |
| Trusted Platform Module (TPM) | Y |
| Product type | Workstation |
| Software | |
| Operating system language | ENG,SWE,FIN,DAN,NOR |
| Operating system installed | Windows 11 Pro for Workstations |
| Power | |
| Power supply | 1000 W |
| 80 PLUS certification | 80 PLUS Platinum |
| Operational conditions | |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Storage relative humidity (H-H) | 10 - 90 % |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
| Certificates | |
| Compliance certificates | RoHS |
| Sustainability | |
| Sustainability certificates | TCO,ENERGY STAR,EPEAT Gold |
| Weight & dimensions | |
| Width | 165 mm |
| Depth | 453.9 mm |
| Height | 446 mm |
| Weight | 19000 g |
| Packaging content | |
| Mouse included | Y |
| Mouse connectivity | Wired |
| Keyboard included | Y |
| Keyboard connectivity | Wired |
| Display | |
| Display included | N |
