TP-Link 6-Port Gigabit Desktop Switch with 3-Port PoE+ and 1-Port PoE++
TP-Link 6-Port Gigabit Desktop Switch with 3-Port PoE+ and 1-Port PoE++, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
Availability: In Stock
TL-SG1006PP is an unmanaged switch with 6 Gigabit ports that requires no configuration and provides4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE802.3af/at/bt compliant Powered Devices (PDs) at port 1 and IEEE 802.3af/at compliant PoweredDevices (PDs) at port 2-4. In this situation, the electrical power is transmitted along with data in onesingle cable allowing you to expand your network to where there are no power lines or outlets, whereyou wish to fix devices such as APs, IP Cameras or IP Phones, etc
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 6 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Network | |
| Networking standards | IEEE 802.1p,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Cable types supported | Cat3,Cat4,Cat5,Cat5e,Cat6 |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Auto-negotiation | Y |
| MAC address auto-learning supported | Y |
| MAC address auto-aging supported | Y |
| Data transmission | |
| Switching capacity | 12 Gbit/s |
| Forwarding rate | 8.928 Mpps |
| MAC address table | 4000 entries |
| Store-and-forward | Y |
| Security | |
| IGMP snooping | Y |
| Design | |
| Rack mounting | Y |
| Stackable | Y |
| Product colour | Grey |
| LED indicators | Y |
| Performance | |
| Fanless | Y |
| Power | |
| Power source | DC/PoE |
| Power supply included | Y |
| DC input voltage | 53.5 V |
| Input current | 1.31 A |
| Power consumption (typical) | 4.75 W |
| Power consumption (max) | 71.46 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) ports quantity | 4 |
| Total Power over Ethernet (PoE) budget | 64 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 5 - 90 % |
| Heat dissipation | 16.2 BTU/h |
| Weight & dimensions | |
| Width | 158 mm |
| Depth | 101 mm |
| Height | 25 mm |
| Packaging content | |
| Quick start guide | Y |
| Packaging data | |
| Package type | Box |
| Certificates | |
| Certification | FCC, CE, RoHS |
