Bosch DIVAR IP all-in-one 5000 NAS Mini Tower Intel® Core™ i3 i3-8100 8 GB DDR 0 TB Black
Bosch DIVAR IP all-in-one 5000, NAS, Mini Tower, Intel® Core™ i3, i3-8100, 8 GB, DDR
Availability: In Stock
The DIVAR IP all-in-one 5000 appliance is an affordableand easy to use all-in-one recording, viewing, andmanagement solution for network surveillance systemsof up to 42 channels (with 8 channels pre-licensed).Running the full BVMS solution and powered byBosch Video Recording Manager including theVideo Streaming Gateway to integrate third-partycameras, it is an intelligent IP video management andstorage device.DIVAR IP all-in-one 5000 is a 4-bay mini tower unit thatcombines advanced management and state-of-the-artrecording management into a single cost-effective,plug and play IP recording appliance for IT-mindedcustomers.Instant real time access to videoView high quality HD or even UHD video despite low orlimited bandwidth connections. Dynamic Transcodingtechnology ensures you can view your videoimmediately — anytime, anywhere.Dynamic Transcoding decodes and re-encodes thedata stream to a lower rate bit stream tailored to thebandwidth of the connection.When the video is paused, the instant detailenhancement feature instantly displays the fullresolution video.ManagementOnce booted up the system will offer immediateaccess to the BVMS management application via acustomized GUI. The ability to use one central GUI forconfiguration and operation management reducesinstallation and training requirements, and helps keepongoing system management costs low.Remote viewingFor remote viewing of a single DIVAR IP all-in-onesystem, BVMS Operator Client is included. Formultiple systems, add them to BVMS EnterpriseManagement Server.Alternatively, use Video Security App for remoteviewing from mobile devices.Bosch qualityBosch subjects all its products to the mostcomprehensive and rigorous battery of qualityendurance tests in the industry. Our recordingproducts are subjected to extreme temperatures,voltages and vibrations to determine reliable operatinglimits, so you can be assured of long-term reliableoperation. And Bosch firmly stands behind everyproduct it sells with an end-to-end 3 year warrantybacked by technical support.
| Storage | |
|---|---|
| Storage drive capacity | 0 GB |
| Supported storage drive interfaces | Serial ATA |
| Storage drive sizes supported | 3.5 " |
| RAID support | N |
| Hot-swap drive bays | Y |
| Storage drives installed | N |
| Total installed storage capacity | 0 TB |
| Number of storage drives supported | 4 |
| Installed storage drive type | N |
| Processor | |
| Processor manufacturer | Intel |
| Processor generation | Intel Core i3-8xxx |
| Processor family | Intel Core i3 |
| Processor model | i3-8100 |
| Processor frequency | 3.6 GHz |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor cache | 6 MB |
| Bus type | DMI3 |
| CPU configuration (max) | 1 |
| PCI Express configurations | 1x16,1x8+2x4,2x8 |
| PCI Express slots version | 3.0 |
| Processor cache type | Smart Cache |
| Processor codename | Coffee Lake |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor package size | 37.5 x 37.5 mm |
| Processor socket | LGA 1151 (Socket H4) |
| Scalability | 1S |
| System bus rate | 8 GT/s |
| Tjunction | 100 °C |
| Thermal Design Power (TDP) | 65 W |
| On-board graphics card model | Intel UHD Graphics 630 |
| Maximum internal memory supported by processor | 64 GB |
| Memory bandwidth supported by processor (max) | 37.5 GB/s |
| Conflict-Free processor | Y |
| Memory | |
| Internal memory | 8 GB |
| Internal memory type | DDR |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ports & interfaces | |
| USB port | Y |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| DisplayPorts quantity | 1 |
| Graphics | |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1100 MHz |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x3E91 |
| Maximum on-board graphics card memory | 64 GB |
| Number of displays supported (on-board graphics) | 3 |
| Design | |
| Chassis type | Mini Tower |
| Product colour | Black |
| Performance | |
| Type | NAS |
| Power | |
| Power supply unit (PSU) capacity | 250 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Width | 210 mm |
| Depth | 279 mm |
| Height | 240 mm |
| Weight | 6800 g |
| Processor special features | |
| Embedded options available | Y |
| Enhanced Intel SpeedStep Technology | Y |
| Execute Disable Bit | Y |
| Idle States | Y |
| Intel 64 | Y |
| Intel Clear Video Technology | Y |
| Intel Enhanced Halt State | Y |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) | N |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Trusted Execution Technology | N |
| Intel TSX-NI | N |
| Intel TSX-NI version | 0.00 |
| Intel Virtualization Technology (VT-x) | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | N |
| Intel® Identity Protection Technology (Intel® IPT) | Y |
| Intel® InTru™ 3D Technology | Y |
| Intel® OS Guard | Y |
| Intel® Quick Sync Video Technology | Y |
| Intel® Secure Key | Y |
| Intel® Turbo Boost Technology | N |
| Maximum number of PCI Express lanes | 16 |
| Number of execution units | 23 |
| Thermal Monitoring Technologies | Y |
| Thermal solution specification | PCG 2015C |
| Memory types supported by processor | DDR4-SDRAM |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 8 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Other features | |
| Processor ARK ID | 126688 |
