Vaddio EasyIP 20 Base Kit with Professional IP PTZ Camera video conferencing system 2.14 MP Ethernet LAN Group video conferencing system
Vaddio EasyIP 20 Base Kit with Professional IP PTZ Camera, Group video conferencing system, 2.38 MP, CMOS, Full HD, 60 fps, 10x
Availability:: Arriving soon
The EasyIP 20 Base Kit is an AV-over-IP professional PTZ camera system in a box. It delivers professional image quality for UC soft clients and simplifies the BYOD (bring your own device) conferencing experience by moving videoconferencing onto the network.This networked video capturing system allows you to use up to four PTZ cameras in your meeting room, without needing a video switch. It’s a simple AV-over-IP solution for extended and networked video capture and streaming in medium and large spaces.The EasyIP 20 Base Kit includes everything you need to get started with AV-over-IP video in one easy-to-order bundle including one EasyIP 20 Camera, one EasyIP Decoder and one EasyIP Switch.
| Performance | |
|---|---|
| Product colour | Black |
| Product type | Group video conferencing system |
| Signal-to-Noise Ratio (SNR) | 60 dB |
| Pan range | -150 - 150 ° |
| Pan speed | 0.35 °/sec |
| Tilt speed | 90 °/sec |
| Tilt angle range | -30 - 90 ° |
| PTZ control | Y |
| Video | |
| HD type | Full HD |
| Total megapixels | 2.38 MP |
| Supported video modes | 1080p |
| Maximum frame rate | 60 fps |
| Aspect ratio | 16:9 |
| Resolution at capture speed | 1920x1080@60fps |
| Audio | |
| Noise reduction | Y |
| Ports & interfaces | |
| HDMI ports quantity | 1 |
| Power over Ethernet plus (PoE+) ports quantity | 2 |
| RS-232 ports | 1 |
| Interface module | |
| Interface module USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 1 |
| Interface module RJ-45 ports quantity | 19 |
| Interface module Ethernet LAN (RJ-45) ports | 3 |
| Network | |
| Ethernet LAN | Y |
| Web-based management | Y |
| Camera | |
| Megapixel (approx.) | 2.14 MP |
| Optical zoom | 10 x |
| Sensor type | CMOS |
| Image sensor size | 1/2.8 " |
| Wide end viewing angle (normal mode) | 74 ° |
| Tele end viewing angle (normal mode) | 7.6 ° |
| Noise reduction number of steps | 16 |
| Focus adjustment | Auto/Manual |
| Wide Dynamic Range (WDR) | Y |
| Number of camera presets | 16 |
| Remote control interface | IR wireless/RS-232 |
| PTZ motors | Stepper |
| Minimum illumination | 100 lx |
| Camera shutter speed | 1/1 - 1/10000 s |
| White balance | Auto,Manual,One push |
| Gain control type | Auto/Manual |
| Features | |
| Invertible | Y |
| Tri-Synchronous Motion Technology | N |
| Control method | IR remote,Joystick,RS-232,Telnet,Web UI |
| OneLink compatibility | N |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Certificates | |
| Certification | CE, FCC, TAA |
| Weight & dimensions | |
| Interface module dimensions (W x D x H) | 439.4 x 209.6 x 44.5 mm |
| Camera dimensions (WxDxH) | 154.9 x 139.7 x 160 mm |
| Width | 213 mm |
| Depth | 152 mm |
| Height | 44 mm |
| Weight | 1260 g |
| Packaging content | |
| Cables included | AC,LAN (RJ-45),Serial,USB |
| Mounting kit | Y |
| Packaging content | EasyIP 20 PTZ Camera (black or white) Thin Profile Wall Mount (black or white) with mounting hardware Vaddio IR Remote Commander EasyIP Switch Rack mount kit (for mounting the EasyIP Switch) EasyIP Decoder Half-Rack mounting kit (for mounting the EasyIP Decoder into a full rack space) 10 ft (3.05m) cat-5e snagless Cable, black 3 ft (0.91 m) cat-5e cable 6 ft (1.8 m) USB 3.0 cable 1 qty 4-position phoenix-style connector Power cord (for EasyIP Switch) Quick-Start Guides |
