Vaddio RoboSHOT 30E NDI 8.57 MP Black 1920 x 1080 pixels 60 fps CMOS 25.4 / 2.5 mm (1 / 2.5")
Vaddio RoboSHOT 30E NDI, 8.57 MP, CMOS, Full HD, 1920 x 1080 pixels, 60 fps, 20x
Availability:: Arriving soon
Professional A/V presentation NDI camera. Simultaneous HDMI and native NewTek NDI® streaming, with one of the lowest signal latencies in the industry. Recommended for broadcast applications, large meeting rooms, lecture halls, and houses of worship.New! Vaddio Deployment ToolSimplify installations by viewing all your Vaddio products across a deployment on one screen with the simple click of a button. The Vaddio Deployment Tool enables you to select devices from the network, choose an action like rebooting the device, unmute the audio, or updating firmware and voilà! – remote troubleshooting success. You can even conduct mass firmware updates on hundreds of devices all at once, which saves you a lot of time.For PTZ video installations that require an NDI® signal, there is no better option than the RoboSHOT® 30E NDI® camera. This Elite Series camera complies with the most rigorous NDI standards to deliver the lowest latency for live, on-air camera control, switching and streaming. Achieve plug and play simplicity by connecting the camera to the network and opening your NewTek control software. This IP-based NDI video camera is instantly available for NDI control and streaming – without installing any additional drivers.Designed with an 1/2.5-type Exmor R CMOS sensor, RoboSHOT Elite cameras deliver striking, high-definition video image quality. Cutting-edge image signal processing (ISP) results in better light-gathering capabilities, incredible contrast and sharp 1080p/60 video, even in dim lighting conditions.RoboSHOT Elite cameras offer enhanced wide dynamic range, which can help correct for environments with uneven lighting by making darker or over-bright areas in video more visible and detailed.The RoboSHOT 30E cameras have a 20x optical zoom and an additional 10x of IntelliZoomTM Image Processing, to zoom greater distances without compromising any resolution quality of the image. Most digital zooms use electronic cropping to get closer to the subject, resulting in fuzzy images. IntelliZoom image processing technology compares patterns found in adjacent pixels and creates new pixels to match selected patterns, resulting in more realistic, higher-quality images.The Elite Series of RoboSHOT PTZ cameras is equipped with Vaddio’s industry-leading Tri-Synchronous Motion technology, allowing all three axes of the camera to move simultaneously for ultra-smooth, natural camera motion.The RoboSHOT 30E cameras are ideal for larger spaces such as large meeting rooms, lecture halls, conference centers, and houses of worship.The RoboSHOT 30E NDI camera complies with the most rigorous NDI standards to deliver the lowest latency for live, on-air camera control, switching and streaming.Video outputs include simultaneous HDMI and NewTek NDI streaming.This Package Includes:- RoboSHOT 30E NDI camera (white or black)- Quick-Start Guide- PoE+ Midspan Power Injector- Thin Profile Wall Mount (white or black) with mounting hardware and installation manual- Vaddio IR Remote Commander
| Camera | |
|---|---|
| Megapixel (approx.) | 8.57 MP |
| Sensor type | CMOS |
| Optical sensor size | 1/2.5 " |
| Effective sensor resolution | 8.51 MP |
| Optical zoom | 20 x |
| Digital zoom | 10 x |
| Combined zoom | 30 x |
| Focal length range | 4.4 - 88.4 mm |
| Horizontal field of view (wide) | 70.2 ° |
| Horizontal field of view (tele) | 3.1 ° |
| Minimum illumination | 1.6 lx |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Aperture number of steps | 16 |
| Aperture range (F-F) | 2 - 3.8 |
| White balance | ATW,Auto,Indoor,Manual,One push,Outdoor |
| Focus adjustment | Auto/Manual |
| Auto focusing (AF) modes | Auto,Manual,One Push Trigger |
| Wide Dynamic Range (WDR) | Y |
| Back Light Compensation (BLC) | Y |
| Number of camera presets | 16 |
| Gain control type | Auto/Manual |
| PTZ control | Y |
| Minimum working distance (wide) | 229 mm |
| Maximum working distance (tele) | 800 mm |
| Aspect ratio | 16:9 |
| Slowest camera shutter speed | 1 s |
| Fastest camera shutter speed | 1/10000 s |
| Video | |
| HD type | Full HD |
| Maximum video resolution | 1920 x 1080 pixels |
| Maximum frame rate | 60 fps |
| Resolution at capture speed | 1920x1080@60fps |
| Supported video modes | 720p,1080i,1080p |
| Design | |
| Product colour | Black |
| Tilt angle range | -30 - 90 ° |
| Pan range | -160 - 160 ° |
| Web-based management | Y |
| Tilt speed (min) | 0.35 °/sec |
| Tilt speed (max) | 120 °/sec |
| Pan speed (min) | 0.35 °/sec |
| Pan speed (max) | 120 °/sec |
| Ports & interfaces | |
| HDMI ports quantity | 1 |
| Power over Ethernet plus (PoE+) ports quantity | 1 |
| RS-232 ports | 1 |
| Power | |
| Power source type | PoE |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Packaging content | |
| Quick start guide | Y |
| Mounting kit | Y |
| Performance | |
| Remote control function | Y |
| Certification | CE, FCC |
| Audio | |
| Noise reduction | Y |
| Network | |
| Network streaming | Y |
| Logistics data | |
| Harmonized System (HS) code | 85258900 |
| Weight & dimensions | |
| Width | 179.1 mm |
| Depth | 171.5 mm |
| Height | 176.3 mm |
| Weight | 2200 g |
