Vaddio ConferenceSHOT AV Bundle - TableMIC 2 w/o Speaker video conferencing system 2.14 MP Ethernet LAN
Vaddio ConferenceSHOT AV Bundle - TableMIC 2 w/o Speaker, CMOS, Full HD, 60 fps, White
Availability:: Arriving soon
Cost-effective USB 3.0 conferencing for small conference rooms. Use the ConferenceSHOT AV camera and one tabletop microphone with your display’s built-in speakers.ConferenceSHOT AV Bundle – TableMIC 1 (without speaker)Ideal for smaller-sized videoconferencing spaces, the ConferenceSHOT AV TableMIC 1 (without speaker) Bundle includes one ConferenceSHOT AV camera, one HDMI Audio Inserter Kit, one TableMIC microphone, plus Thin Profile Wall Mount with mounting hardware.PowerfulConferenceSHOT AV integrates a 10x zoom PTZ camera and audio conferencing mixer into a single USB 3.0 device, so you can easily connect a microphone and external speaker to the camera. The TableMIC 1 (without speaker) Bundle is easy to install and allows simple plug and play functionality with all major UCC soft clients such as Skype for Business, WebEx and Google.The HDMI Audio Embedder included in this bundle allows you to use the built-in speakers in your HDMI display for a great-sounding video call. The HDMI video and the audio signal enter the injector box separately and come out together as HDMI video + audio signal which goes to your display.SimpleConferenceSHOT AV is UVC compliant. No external drivers need to be installed on your PC – just plug and play. The versatile system supports customized AV designs with third-party equipment or can be deployed as a standalone solution.Enterprise-ClassConferenceSHOT AV allows for remote monitoring, management and control of a distributed camera network. IP-accessible and a browser-based user interface enables both browser control and IP-live preview and setup from PCs, Macs and mobile devices including iPhone, iPad and Android devices.This USB-based solution makes it easy for your organization to collaborate using Skype for Business, WebEx, Zoom, BlueJeans, Google Hangouts, Vidyo and other leading UC services.
| Performance | |
|---|---|
| Product colour | White |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Pan range | -165 - 165 ° |
| Pan speed | 90 °/sec |
| Tilt speed | 90 °/sec |
| Tilt angle range | -30 - 90 ° |
| Video | |
| HD type | Full HD |
| Supported video modes | 480p,720p,1080p |
| Maximum frame rate | 60 fps |
| Video codecs | H.264 |
| Audio | |
| Frequency range | 20 - 20000 Hz |
| Line-out impedance | 50 Ω |
| Output voltage Total Harmonic Distortion (THD) | 0.02 % |
| Noise reduction | Y |
| Echo cancellation | Y |
| Automatic gain control | Y |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Power over Ethernet plus (PoE+) ports quantity | 1 |
| Line-out | Y |
| Interface module | |
| Interface module HDMI ports quantity | 2 |
| Interface module HDMI input ports quantity | 1 |
| Interface module HDMI output ports quantity | 1 |
| Interface module audio RCA input ports quantity | 2 |
| Interface module audio optical input ports quantity | 1 |
| Interface module DC input port | Y |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Web-based management | Y |
| Management protocols | Telnet |
| Camera | |
| Megapixel (approx.) | 2.14 MP |
| Effective sensor resolution | 2.14 MP |
| Sensor type | CMOS |
| Image sensor size | 1/2.8 " |
| Focal length range (normal mode) | 3.8 - 38 mm |
| Optical zoom (normal mode) | 10 x |
| Optical zoom (super-wide mode) | 11 x |
| Wide end viewing angle (normal mode) | 67 ° |
| Tele end viewing angle (normal mode) | 7.6 ° |
| Wide end viewing angle (super-wide mode) | 74 ° |
| Tele end viewing angle (super-wide mode) | 7.6 ° |
| Focus adjustment | Auto/Manual |
| Remote control interface | IR wireless |
| Aperture range (F-F) | 1.8 - 3.4 |
| Minimum illumination | 100 lx |
| Aperture number of steps | 16 |
| White balance | Auto,Manual,One push |
| Closest focusing distance (wide) | 0.01 m |
| Closest focusing distance (tele) | 1 m |
| Lens modes | Normal lens mode,Super-wide lens mode |
| Sync system | Internal |
| Gain control type | Auto/Manual |
| Microphone | |
| Microphone colour | Black |
| Microphone sensitivity | 90 dB |
| Microphone frequency | 100 - 16000 Hz |
| Microphone Total Harmonic Distortion (THD) | 0.02 % |
| Number of microphones | 2 |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Storage temperature (T-T) | -5 - 60 °C |
| Storage relative humidity (H-H) | 20 - 80 % |
| Power | |
| Power over Ethernet (PoE) power per port | 25 W |
| Certificates | |
| Certification | CE Approved, FCC Approved, UL Listed, TAA Compliant |
| Weight & dimensions | |
| Camera dimensions (WxDxH) | 155 x 145 x 163 mm |
| Camera weight | 1360 g |
| Packaging content | |
| Number of microphones included | 1 |
| PoE adapter included | Y |
| Mounting kit | Y |
| Speaker included | Y |
| Camera included | Y |
| Microphone included | Y |
