Vaddio RoboSHOT 12E NDI 8.57 MP Black 1920 x 1080 pixels 60 fps CMOS 25.4 / 2.5 mm (1 / 2.5")
Vaddio RoboSHOT 12E NDI, 8.57 MP, CMOS, Full HD, 1920 x 1080 pixels, 60 fps, 12x
Availability:: Arriving soon
Professional A/V presentation NDI camera. Simultaneous HDMI and native NewTek NDI® streaming, with one of the lowest signal latencies in the industry. Recommended for broadcast applications, conference rooms, and classrooms.New! Vaddio Deployment ToolSimplify installations by viewing all your Vaddio products across a deployment on one screen with the simple click of a button. The Vaddio Deployment Tool enables you to select devices from the network, choose an action like rebooting the device, unmute the audio, or updating firmware and voilà! – remote troubleshooting success. You can even conduct mass firmware updates on hundreds of devices all at once, which saves you a lot of time.For PTZ video installations that require an NDI® signal, there is no better option than the RoboSHOT® 12E NDI® camera. This Elite Series camera complies with the most rigorous NDI standards to deliver the lowest latency for live, on-air camera control, switching and streaming. Achieve plug and play simplicity by connecting the camera to the network and opening your NewTek control software. This IP-based NDI video camera is instantly available for NDI control and streaming – without installing any additional drivers.Designed with an 1/2.5-type Exmor R CMOS sensor, RoboSHOT Elite cameras deliver striking, high-definition video image quality. Cutting-edge image signal processing (ISP) results in better light-gathering capabilities, incredible contrast and sharp 1080p/60 video, even in dim lighting conditions.RoboSHOT Elite cameras offer enhanced wide dynamic range, which can help correct for environments with uneven lighting by making darker or over-bright areas in video more visible and detailed.The Elite Series of RoboSHOT PTZ cameras is equipped with Vaddio’s industry-leading Tri-Synchronous Motion technology, allowing all three axes of the camera to move simultaneously for ultra-smooth, natural camera motion.The RoboSHOT 12E cameras are ideal for small to medium spaces such as conference rooms, training rooms, and classrooms that require a wide angle of view.The RoboSHOT 12E NDI camera complies with the most rigorous NDI standards to deliver the lowest latency for live, on-air camera control, switching and streaming.Video outputs include simultaneous HDMI and NewTek NDI streaming.This Package Includes:- RoboSHOT 12E NDI camera (white or black)- Quick-Start Guide- PoE+ Midspan Power Injector- Thin Profile Wall Mount (white or black) with mounting hardware and installation manual- Vaddio IR Remote Commander
| Camera | |
|---|---|
| Megapixel (approx.) | 8.57 MP |
| Sensor type | CMOS |
| Optical sensor size | 1/2.5 " |
| Effective sensor resolution | 8.51 MP |
| Optical zoom | 12 x |
| Focal length range | 4.4 - 88.4 mm |
| Horizontal field of view (wide) | 70.2 ° |
| Horizontal field of view (tele) | 6.8 ° |
| Minimum illumination | 1.6 lx |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Aperture number of steps | 16 |
| Aperture range (F-F) | 2 - 3.8 |
| White balance | ATW,Auto,Indoor,Manual,One push,Outdoor |
| Focus adjustment | Auto/Manual |
| Auto focusing (AF) modes | Auto,Manual,One Push Trigger |
| Wide Dynamic Range (WDR) | Y |
| Back Light Compensation (BLC) | Y |
| Number of camera presets | 16 |
| Gain control type | Auto/Manual |
| PTZ control | Y |
| Minimum working distance (wide) | 229 mm |
| Aspect ratio | 16:9 |
| Slowest camera shutter speed | 1 s |
| Fastest camera shutter speed | 1/10000 s |
| Video | |
| HD type | Full HD |
| Maximum video resolution | 1920 x 1080 pixels |
| Maximum frame rate | 60 fps |
| Resolution at capture speed | 1920x1080@60fps |
| Supported video modes | 720p,1080i,1080p |
| Design | |
| Product colour | Black |
| Tilt angle range | -30 - 90 ° |
| Pan range | -160 - 160 ° |
| Web-based management | Y |
| Tilt speed (min) | 0.35 °/sec |
| Tilt speed (max) | 120 °/sec |
| Pan speed (min) | 0.35 °/sec |
| Pan speed (max) | 120 °/sec |
| Ports & interfaces | |
| HDMI ports quantity | 1 |
| Power over Ethernet plus (PoE+) ports quantity | 1 |
| RS-232 ports | 1 |
| Power | |
| Power source type | PoE |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Packaging content | |
| Quick start guide | Y |
| Mounting kit | Y |
| Performance | |
| Remote control function | Y |
| Audio | |
| Noise reduction | Y |
| Network | |
| Network streaming | Y |
| Logistics data | |
| Harmonized System (HS) code | 85258900 |
| Weight & dimensions | |
| Width | 179.1 mm |
| Depth | 171.5 mm |
| Height | 176.3 mm |
| Weight | 2200 g |
