NETGEAR MSM4310 Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Black
NETGEAR MSM4310, Managed, L3, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting, 1U
Availability: Arriving Soon
POWER AND THROUGHPUTEdge to core flexible platform, from 1 Gigabit to 100 Gigabit, good for projects of all sizes.Groundbreaking AV GUIA simplified user interface makes it easy to assign configuration profiles to each port.Multicast in an InstantNETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.Sleek, Quiet DesignLess fan noise, and mounting ears included for rack mounting.Automatic ConfigurationAuto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.FAST, EASY CONFIGURATION FOR AV PROSA streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.FOCUS ON THE EVENT NOT FAN NOISEMost models have quiet mode which greatly reduces fan noise.DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOXWith built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless audio and video delivery. Enable multicasting right out of the box.MAXIMIZE PERFORMANCE WITH PRO WIFI ACCESS POINTSEnable powerful, reliable WiFi at your location with Pro WiFi access points, powered by PoE or an external power adapter.PRO AV RESOURCESAll the resources you need to learn about NETGEAR AV over IP solutions, including family brochures, product data sheets, tech tips and more.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| ARP inspection | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (copper) ports quantity | 8 |
| 10G Ethernet (copper) ports quantity | 8 |
| SFP28 ports quantity | 2 |
| Power connector | AC-in jack |
| Network | |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1Qav,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ak,IEEE 802.3bz,IEEE 802.3u |
| 10G support | N |
| Full duplex | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Spanning tree protocol | Y |
| 6to4 tunnel | Y |
| IPv4 routes | 512 |
| IPv6 routes | 256 |
| VLAN support | Y |
| Virtual LAN features | MAC address-based VLAN,Private VLAN,Voice VLAN |
| Number of VLANs | 4093 |
| Data transmission | |
| Switching capacity | 140 Gbit/s |
| Throughput | 372 Mpps |
| MAC address table | 16000 entries |
| Store-and-forward | Y |
| Latency (10 Gbps) | 2.27 µs |
| Jumbo frames support | Y |
| Jumbo frames | 12000 |
| Packet buffer memory | 32 MB |
| Security | |
| DHCP features | DHCP Option 150,DHCP Option 66,DHCP Option 67,DHCP relay,DHCP server,DHCP snooping |
| Access Control List (ACL) | Y |
| Access Control List (ACL) egress | 1023 |
| Access Control List (ACL) ingress | 511 |
| IGMP snooping | Y |
| IGMP proxy | Y |
| MAC address filtering | Y |
| Static port security | Y |
| Loop protection | Y |
| BPDU filtering/protection | Y |
| Authentication | Guest VLAN,MAC-based authentication |
| Root protection | Y |
| Password protection | Y |
| DoS attack prevention | Y |
| Authentication type | RADIUS,TACACS+ |
| Queue scheduling algorithms | Strict Priority Queue (SPQ),Weighted random early detection (WRED) |
| Multicast features | |
| Multicast support | Y |
| Multicast Listener Discovery (MLD) snooping | Y |
| Protocols | |
| Management protocols | SNMP V1, V2, V3 |
| GARP VLAN Registration Protocol (GVRP) | Y |
| Routing protocols | OSPF,OSPFv2,OSPFv3,RIP,RIP-1,RIP-2 |
| Design | |
| Rack mounting | Y |
| Stackable | Y |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Y |
| Airflow direction | Front-to-back airflow |
| Performance | |
| Built-in processor | Y |
| Processor model | ARM Cortex-A57 |
| Processor frequency | 1800 MHz |
| Memory type | DDR4-SDRAM |
| Internal memory | 2048 MB |
| Flash memory | 512 MB |
| sFlow | Y |
| Power | |
| Power source | AC |
| Power supply included | Y |
| Power consumption (typical) | 133.5 W |
| Power consumption (max) | 351.5 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 48 |
| Power over Ethernet (PoE) power per port | 90 W |
| Total Power over Ethernet (PoE) budget | 3314 W |
| Other features | |
| Power supply | 550 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 3000 m |
| Weight & dimensions | |
| Width | 220 mm |
| Depth | 300 mm |
| Height | 43.2 mm |
| Weight | 2900 g |
| Packaging content | |
| Cables included | AC,USB Type-C |
| Quick start guide | Y |
| Rack mount kit | Y |
| Packaging data | |
| Included power plug types | EU,UK,NA |
| Sustainability | |
| Sustainability compliance | Y |
| Certificates | |
| Compliance certificates | BSMI,CCC,CE,Federal Communications Commission (FCC),Low Voltage Directive (LVD) |
