NEC PA1705UL 16000 ANSI lumens 3LCD WUXGA (1920x1200) 3D Black
NEC PA1705UL, 16000 ANSI lumens, 3LCD, WUXGA (1920x1200), 3000000:1, 16:10, 1524 - 12700 mm (60 - 500")
Availability:: Arriving soon
A new class of bright projectionNow even larger spaces can benefit from Sharp/NEC’s innovation in silent technology with the 17,000 center lumens PA1705UL laser projector, ensuring all attention is focused on the stunning image delivery.Featuring unprecedented White Point performance, factory pre-calibrated for the perfect white, 12-bit colour signal processing and wide colour space, the audience will experience extraordinarily vivid colour saturation and contrast levels.The enhanced sealed optical engine allows a filter-free design, IP5X rated against dust ingress - no possibility of dust contaminating the LCD panels for long-term picture stability and brilliant colour brightness. What’s more, with our filterless LCD projector design and no lamp replacement, service costs are dramatically reduced for a low cost of ownership and up to 20,000 hours life-time.Sharp/NEC customers can easily make the transition to benefit from the latest laser technology. The PA1705UL is a professional installation projector featuring advanced installation capabilities as demanded by higher education, leisure and museum applications.
| Projector | |
|---|---|
| Screen size compatibility | 60 - 500 " |
| Projection distance | 0.68 - 80.77 m |
| Projector brightness | 16000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Contrast ratio (typical) | 3000000:1 |
| Native aspect ratio | 16:10 |
| Keystone correction, horizontal | +/- 40 ° |
| Keystone correction, vertical | +/- 30 ° |
| Light source | |
| Light source type | Laser |
| Service life of light source | 20000 h |
| Lens system | |
| Focus | Motorized |
| Zoom capability | Y |
| Horizontal lens shift range | -25 - 25 % |
| Vertical lens shift range | -65 - 65 % |
| Video | |
| 3D | Y |
| Supported graphics resolutions | 640 x 480 (VGA),1920 x 1200 (WUXGA),2048 x 1080,2560 x 1600 (WQXGA),4096 x 2160 |
| Supported video modes | 720p,1080i,1080p |
| Video colour modes | DICOM simulation mode |
| Ports & interfaces | |
| HDBaseT port | Y |
| USB 2.0 ports quantity | 1 |
| Headphone outputs | 1 |
| Serial interface type | RJ-45,RS-232 |
| PC in (D-Sub) | Y |
| HDMI ports quantity | 2 |
| 3G-SDI input | 1 |
| AC (power) in | Y |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN (RJ-45) ports | 1 |
| Features | |
| Noise level (economic mode) | 37 dB |
| HDCP | Y |
| Noise level | 43 dB |
| Certification | CE; EAC; ErP; RoHS; TUEV Type Approved |
| Design | |
| Market positioning | Education |
| Product colour | Black |
| Display | |
| Built-in display | N |
| Power | |
| Power source | AC |
| Power consumption (typical) | 995 W |
| Power consumption (standby) | 2 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Storage relative humidity (H-H) | 20 - 80 % |
| Weight & dimensions | |
| Width | 599 mm |
| Depth | 490 mm |
| Height | 238 mm |
| Weight | 28700 g |
| Packaging content | |
| Remote control included | Y |
| Remote control type | IR |
| Cables included | AC |
| Manual | Y |
