Multibrackets M Pro Series - Shelf Mount 75x75 100x100 White
Multibrackets M Pro Series - Shelf Mount 75x75 100x100 White, 10 kg, 55.9 cm (22"), 25.4 cm (10"), 75 x 75 mm, 100 x 100 mm
Availability:: Arriving soon
The M Pro Series Shelf Mount 75x75 100x100 from Multibrackets is a compact and theft-resistant display bracket designed for use in retail and industrial environments. Ideal for mounting small digital signage screens directly onto store shelves or walls, it supports both VESA 75x75 and 100x100 mounting patterns.This mount accommodates displays from brands like Samsung, LG, and ELO, and can be used with or without an enclosure. It’s perfect for promoting featured products, showing live messaging, or running visual content in high-traffic areas—directly at the point of sale.Built with steel for strength and reliability, it ensures quick installation, adjustable depth, and a professional appearance with integrated cable management. Scandinavian design meets practical deployment for modern retail installations.
| Mounting | |
|---|---|
| Maximum weight capacity | 10 kg |
| Minimum screen size | 10 " |
| Number of displays supported | 1 |
| Maximum weight capacity (per display) | 10 kg |
| Maximum screen size | 22 " |
| Mounting type | Shelf |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Ergonomics | |
| Cable management | Y |
| Design | |
| Product colour | White |
| Housing material | Steel |
| Compatible products | ELO: 0702L 1002L 1304LS 1302L 1502L 2002L 2202L 2270L 2402L 2470L 1515L 1517L 1523L 1715L 1717L 1723L 1902L 1915L 1502LM 1903LM 2203LM 2403LM ELO Android 10": E389883 E411266 E746741 E390647 E411643 E792262 ELO Android 15": E390075 E412033 E746926 E391032 E412421 E792461 ELO Android 22": E574316 E390263 E412818 E747123 E391414 E413211 E792655 |
| Weight & dimensions | |
| Width | 175 mm |
| Depth | 145.5 mm |
| Height | 134.1 mm |
| Weight | 690 g |
| Aluminium content weight | 0 g |
| Steel content weight | 690 g |
| Other metals content weight | 0 g |
| Packaging data | |
| Package width | 180 mm |
| Package depth | 84 mm |
| Package height | 128 mm |
| Package weight | 900 g |
| Package type | Box |
| Technical details | |
| Orientation | Landscape/Portrait |
| Warranty period | 5 year(s) |
| Paper/cardboard packaging weight | 200 g |
| Metal packaging weight | 0 g |
| Plastic packaging weight | 10 g |
