Multibrackets M Pro Series - Video Wall Stand MBF2x3U
Multibrackets M Pro Series - Video Wall Stand MBF2x3U, 180 kg, 81.3 cm (32"), 165.1 cm (65"), 75 x 75 mm, 400 x 400 mm, -4 - 4°
Availability:: Arriving soon
The M Pro Series Video Wall Stand MBF2x3U 300 Micro Adjustable is a professional-grade freestanding video wall system designed for high-impact visual environments. Supporting a 2x3 screen array—two screens wide and three high—this solution is ideal for digital signage, control rooms, corporate lobbies, or exhibitions. Each aluminum pillar measures 300 cm in height, ensuring clear visibility for both seated and standing audiences.Engineered to hold displays between 32” and 65” (up to 30 kg per screen), the structure features micro-adjustable VESA 400x400 brackets with fine-tuning on the X, Y, and Z axes—even after installation. This ensures pixel-perfect alignment across all six displays. Built within the modular Multibrackets Pro Series ecosystem, this stand is easy to configure, reconfigure, and expand as needs change over time. All screens remain accessible for maintenance and service.This video wall stand offers the flexibility of a mobile or semi-permanent installation, making it an excellent choice for any commercial or event-based application requiring both precision and adaptability.
| Mounting | |
|---|---|
| Maximum weight capacity | 180 kg |
| Minimum screen size | 32 " |
| Number of displays supported | 6 |
| Maximum weight capacity (per display) | 30 kg |
| Maximum screen size | 65 " |
| Mounting type | Floor |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 75 x 75,100 x 100,200 x 200,300 x 300,400 x 400 mm |
| Ergonomics | |
| Height adjustment | 10 mm |
| Tilt angle range | -4 - 4 ° |
| Tilt adjustment | Y |
| Design | |
| Product colour | Black |
| Housing material | Aluminium,Plastic,Steel |
| Weight & dimensions | |
| Width | 1970 mm |
| Depth | 610 mm |
| Height | 3010 mm |
| Weight | 83770 g |
| Aluminium content weight | 13200 g |
| Steel content weight | 83756.8 g |
| Other metals content weight | 0 g |
| Packaging data | |
| Package weight | 91000 g |
| Technical details | |
| Warranty period | 5 year(s) |
| Paper/cardboard packaging weight | 7000 g |
| Metal packaging weight | 0 g |
| Plastic packaging weight | 230 g |
