APC NetShelter power distribution unit (PDU) 42 AC outlet(s) 0U Black
(0 review)Add your review
€5034,95

APC NetShelter, Metered, 0U, Three-phase, Black, 42 AC outlet(s), C13 coupler, C15 coupler, C19 coupler, C21 coupler

Availability: In Stock
EAN:0731304752790Categories:PowerTags:

APC NetShelter Rack PDU Advanced (11K Series) provides reliable power distribution to IT equipment within server and/or networking racks. Switched outlets allow for turning outlets on or off remotely. Outlet and PDU level power metering provide power visibility and notification of potential overload. 4-in-1 combination outlets which can be used as either C13, C19, C15, or C21 outlets provide unparalleled deployment flexibility. Maximum outlet density with 42 outlets in a 2.2 in. (5.6 cm) wide form factor allows for more equipment in the rack. Outlets on the PDUs are color coded and labeled by breaker. Live Swap the NMC3 to minimize downtime in the unlikely event of an NMC power event. The rack PDU integrates with EcoStruxure IT through an NMC3 and can be accessed and configured via web, SNMP, and command line interface (CLI). A 10-foot (3-meter) input cord makes it easier for the PDU to reach the power supply. Rated to operate up to 60 C (140 F) at full load ensures reliability and availability even in today's high-density deployments. One gigabit Ethernet/network port (10/100/1000) enhances and standardizes network connectivity. Two link ports are available to cascade to up to 32 PDUs, with a network port sharing (NPS) feature to enable power sharing between Rack PDUs in the cascading group. Track or bill power usage confidently with 1% metering accuracy. Two environmental sensor ports allow for optional sensors (sold separately) to be connected. For data center deployments across multiple regions, these PDUs have the following certifications: UL, CE, CSA, UKCA, Nemiko, PSE, KC, China RoHS, RCM, and CMIM. This model’s input power cord is IEC-309 60 A 3P+N+PE and features 21 count C13/C15/C19/C21 combo outlets and 21 count C13/C15 outlets.

Design
PDU typesMetered
TypeThree-phase
Rack capacity0U
Product colourBlack
Ports & interfaces
AC outlets quantity42 AC outlet(s)
AC outlet typesC13 coupler,C15 coupler,C19 coupler,C21 coupler
Ethernet LAN (RJ-45) ports5
USB ports quantity1
Management features
Management platformNMC3
Power
Nominal input voltage400 V
AC input frequency50/60 Hz
Maximum current60 A
Nominal output voltage400 V
Load capacity34600 VA
Number of phases3
Certificates
Compliance certificatesRoHS
Weight & dimensions
Width56 mm
Depth75 mm
Height1826 mm
Weight11700 g
Packaging data
Package weight17000 g
Package width132 mm
Package depth262 mm
Package height2110 mm
