Multibrackets M Wallmount Pro MBSTH1U 400x200 Fixed Black
Multibrackets M Wallmount Pro MBSTH1U 400x200 Fixed Black, 50 kg, 94 cm (37"), 100 x 100 mm, 400 x 200 mm
Availability:: Arriving soon
Multibrackets Pro Series M Wallmount Pro MBSTH1U 400x200 Fixed Black is our innovative - ready to be installed Single-Display Wallmount.This mount is suited for Ultra-Stretch Digital Signage screens like Samsung LH37SHFPLBB/EN when landscape mounted.The new professional Pro Series A/V line from Multibrackets was designed with the installer in mind. Modular, easy to configure, quick to install, and simple to maintain. Working closely with installers we created a range with close to unlimited flexibility. This model the M Wallmount Pro MBSTH1UP is no exception. The product provides the versatility and flexibility demanded by installers. Based upon the Pro Series strong and ultra-flexible aluminum rail it is completely modular and has built in cable management throughout the entire solution to quicken installation and creating an esthetic result worth the public eye.With its modular construction installers have vast possibilities to change, create, update and reconfigure its design if ideas change over time, then Pro Series can follow.Designed with our Scandinavian heritage in mind and providing a clean Nordic look each part and detail serves its purpose. The result is a sleek Nordic solution emphasizing quality and function. Used in a variety of environments this ceiling mount is truly versatile and is made of the highest quality materials.The Pro Series possibilities to extend aluminum rail change brackets and add details by individual choice is vast so that one can tailor each mount to its location and function.The Pro Series includes hardware so that a basic installation should not be a hassle.Multibrackets Pro Series Public Wallmounts is ideal for any large screen digital signage wallmount application such as videowalls, menuboards and more.
| Mounting | |
|---|---|
| Maximum weight capacity | 50 kg |
| Number of displays supported | 1 |
| Maximum screen size | 37 " |
| Mounting type | Wall |
| Minimum VESA mount | 100 x 100 mm |
| Maximum VESA mount | 400 x 200 mm |
| Panel mounting interface | 100 x 100,200 x 200,400 x 200 mm |
| Ergonomics | |
| Angle of rotation | 8 ° |
| Cable management | Y |
| Rotating | Y |
| Design | |
| Product colour | Black |
| Housing material | Aluminium,Plastic,Steel |
| Certification | CE |
| Weight & dimensions | |
| Width | 492 mm |
| Depth (max) | 160 mm |
| Height | 86 mm |
| Weight | 2770 g |
| Aluminium content weight | 0 g |
| Steel content weight | 2770 g |
| Other metals content weight | 0 g |
| Packaging data | |
| Package width | 176 mm |
| Package depth | 495 mm |
| Package height | 60 mm |
| Package weight | 3000 g |
| Package type | Box |
| Technical details | |
| Paper/cardboard packaging weight | 200 g |
| Metal packaging weight | 0 g |
| Plastic packaging weight | 30 g |
| Logistics data | |
| Products per shipping (inner) case | 1 pc(s) |
