LG 75XS4P-B.AEU Signage Display Digital signage flat panel 190.5 cm (75") LED 4000 cd/m² UHD+ Black WebOS 24/7
LG 75XS4P-B.AEU, Digital signage flat panel, 190.5 cm (75"), LED, 3840 x 2160 pixels, 24/7
Availability:: Arriving soon
Attract Passing Customers with a Bright Display Presented Through a WindowWorld’s First UL Verification for Display Anti-Discoloration CharacteristicsBy focusing on the pain points of our customers, we obtained the world’s first UL Verification for Display Anti-Discoloration Characteristics. Our new technology helps prevent ‘screen-yellowing’, while safeguarding display quality and performance stability.Window-facing DisplayLG offers advanced technical solutions for cost-effective operations. The XS4P can maintain an astonishing brightness of 4,000 nits, yet has lower power consumption compared to RGB panels at the same brightness level.Brightness Beyond the WindowA window-facing display requires higher nits, as it is exposed to direct sunlight through a window. The XS4P is designed especially for window-facing environments, providing brilliant brightness. Vibrant and dynamic content displayed through the window will attract customers to your business, despite the viewers wearing polarized sunglasses.High-performance with webOS 6.0Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 6.0 platform enhances not only user convenience with intuitive UI but also web-app integration with updated Node JS / Chromium version.Remotely Managed, Real-time Mastery (Content Manager)A significant advantage of window-facing displays over temporary displays is their ability to effortlessly manage frequently changing promotional content and pricing information. LG’s web-based content solution is intuitive and user-friendly, providing users with complete access to current and historical data anytime, anywhere, through their mobile devices. This allows users to monitor, adjust, and control the unit remotely in real-time.Wide Range of Operating TemperatureThe XS4P can be used under a wide range of operating temperature from 0℃ to 40℃.Conformal CoatingThe conformal coating with dust protection shields the circuit and power boards from dust, metal particles, moisture, and other contaminants, providing solid durability and long-term reliability.Upgraded Quite ModeThe XS4P addresses concerns about display noise. It features an Upgraded Quiet Mode that operates at 2,500 nits with minimal fan noise.Professional Content PartnersPairing the XS4P Series with LG SW solutions would enhance its utilization.Convenient Installation with Calculated PrecisionThe XS4P is equipped with a Leveler Tool that shows users the tilt of the device, allowing for precise display installation. Additionally, the Horizontal Sensor Tool assists users in verifying the correct installation direction. The XS4P even provides warning messages for proper installation if it is installed incorrectly.
| Display | |
|---|---|
| Panel type | IPS |
| LED backlight | Y |
| LED backlighting type | Direct-LED |
| Display diagonal | 75 " |
| Display technology | LED |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 4000 cd/m² |
| HD type | UHD+ |
| Touchscreen | N |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 500000:1 |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Display number of colours | 1.07 billion colours |
| Panel life | 50000 h |
| Native refresh rate | 60 Hz |
| Haze rate | 3 % |
| Ports & interfaces | |
| HDMI ports quantity | 2 |
| HDMI input ports quantity | 2 |
| DVI-D ports quantity | 1 |
| DisplayPorts quantity | 2 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| USB port | Y |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio (L/R) out | 1 |
| Number of speaker outputs | 1 |
| RS-232C | Y |
| Infrared data port | Y |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| Audio | |
| Built-in speaker(s) | Y |
| RMS rated power | 20 W |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Outdoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Screen shape | Flat screen |
| VESA mounting | Y |
| Panel mounting interface | 600 x 400 mm |
| Bezel width (side) | 13.8 mm |
| Bezel colour | Black |
| Performance | |
| Purpose | Retail |
| On Screen Display (OSD) | Y |
| Number of OSD languages | 22 |
| On Screen Display (OSD) languages | ARA,CHI (SIMPL),CHI (TR),CZE,DAN,DEU,DUT,ENG,ESP,FIN,FRE,GRE,ITA,JPN,KOR,NOR,POL,POR,RUS,SWE,TUR |
| Operating hours (hours/days) | 24/7 |
| HDCP | Y |
| HDCP version | 1.4/2.2 |
| Power | |
| Power consumption (typical) | 750 W |
| Power consumption (off) | 0.5 W |
| Power consumption (max) | 790 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Heat dissipation | 2559 BTU/h |
| Computer system | |
| Computer system | Y |
| Computer system type | System on Chip (SoC) |
| Internal memory | 16 GB |
| Operating system installed | WebOS |
| Operating system version | 6.0 |
| Weight & dimensions | |
| Display width | 1679.2 mm |
| Display depth | 104 mm |
| Display height | 957.6 mm |
| Display weight | 39600 g |
| Packaging data | |
| Package width | 1816 mm |
| Package depth | 285 mm |
| Package height | 1106 mm |
| Package weight | 50000 g |
| Packaging content | |
| Remote control included | Y |
| Cables included | AC,HDMI |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80 % |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 5 - 85 % |
| Network | |
| Ethernet LAN | Y |
| Features | |
| Suitable for outdoor use | Y |
| Heat dissipation (max) | 2696 BTU/h |
| Technical details | |
| Introduction year | 24 |
| Other features | |
| Manual | Y |
