LG 55EF5K-P Signage Display 139.7 cm (55") OLED 400 cd/m² Full HD Black 18/7
LG 55EF5K-P, 139.7 cm (55"), OLED, 1920 x 1080 pixels, 18/7
Availability:: Arriving soon
Artistic Space beyond Display LG OLED SignageBlending in with the space while captivating everyone’s mind. LG OLED signage offers flexible design. Beyond its informative features, LG OLED signage delivers unsurpassed advertising effectiveness, redesigning space as a prestige-enhancing landmark with perfect colors and innovative forms.Expandable Screen SizeThe screen size can be as large as users want by tiling up displays horizontally and vertically. This provides viewers with an incredibly immersive viewing experience.Splendid DesignLG OLED technology doesn’t require a backlight unit nor a liquid crystal layer so it offers a flexible design with unbelievably lightweight and slim features.Absolute BlackEquipped with over 8 million self-lighting pixels operating individually, LG OLED Signage reproduces absolute blacks with no light bleed and offers infinite contrast.Rich ColorLG OLED Signage provides richness in all colors, bringing colors to life with great accuracy and vividness.Variety of Curvature for LandmarksThe EF5K series supports various concave and convex curvature in both portrait and landscape orientations. You can differentiate your space in a variety of ways with beautifully curved displays to keep passengers captivated and immersed.On-site CustomizationThe EF5K series enables a completely new approach for innovative and flexible designs. Its optional "Curvature Calibrator(CC)*" supports the coordination of displays with various convex and concave curvature, depending on the requirements. This makes it possible to rapidly respond to changes on-site, making it easier to successfully build an eye-catching landmark.LAN Daisy Chain ManagementThe LAN daisy chain allows users to control and monitor displays, transmit data and even update firmware all at once, reducing management burden.Videowall Playlist & Sync PlaybackThrough its built-in high performance SoC, each display plays its video tile for synchronized content playback.
| Display | |
|---|---|
| Display diagonal | 55 " |
| Display technology | OLED |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 400 cd/m² |
| HD type | Full HD |
| Touchscreen | N |
| Native aspect ratio | 16:9 |
| Response time | 1 ms |
| Contrast ratio (dynamic) | 150000:1 |
| Viewing angle, horizontal | 178 ° |
| Viewing angle, vertical | 178 ° |
| Display number of colours | 1.07 billion colours |
| Number of displays | 1 |
| Panel life | 30000 h |
| Colour depth | 10 bit |
| Native refresh rate | 60 Hz |
| Surface hardness | 2H |
| Colour gamut | 120 % |
| Ports & interfaces | |
| HDMI ports quantity | 1 |
| DVI port | N |
| DisplayPorts quantity | 2 |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| USB port | Y |
| USB ports quantity | 1 |
| USB version | 2.0 |
| USB connector type | USB Type-A |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232C | Y |
| Infrared data port | Y |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| PC Audio out | Y |
| Audio | |
| Built-in speaker(s) | N |
| Design | |
| Placement supported | Indoor |
| Orientation | Vertical |
| Product colour | Black |
| Screen shape | Curved screen |
| VESA mounting | N |
| Mounting type | Wall |
| Performance | |
| Purpose | Commercial |
| Multi-display supported | Y |
| On Screen Display (OSD) | Y |
| Number of OSD languages | 20 |
| On Screen Display (OSD) languages | ARA,CHI (SIMPL),CHI (TR),CZE,DAN,DEU,DUT,ENG,ESP,FIN,FRE,GRE,ITA,JPN,KOR,NOR,POR,RUS,SWE |
| Operating hours (hours/days) | 18/7 |
| HDCP | Y |
| HDCP version | 1.4 |
| Power | |
| Power consumption (typical) | 309 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.5 W |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 116 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Heat dissipation | 1054 BTU/h |
| Energy efficiency scale | A to G |
| Weight & dimensions | |
| Display width | 701.4 mm |
| Display depth | 38 mm |
| Display height | 1219.7 mm |
| Display weight | 7000 g |
| Base width | 413 mm |
| Base depth | 57.3 mm |
| Base height | 353 mm |
| Base weight | 3500 g |
| Weight (with stand) | 10500 g |
| Packaging data | |
| Package width | 1360 mm |
| Package depth | 252 mm |
| Package height | 842 mm |
| Package weight | 17600 g |
| Packaging content | |
| Stand included | Y |
| Stand colour | Grey |
| Remote control included | Y |
| Batteries included | Y |
| Cables included | AC,DisplayPort,LAN (RJ-45),RS-232 |
| Mounting kit | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80 % |
| Certificates | |
| Certification | IEC 60950-1 / EN 60950-1 / UL 60950-1 / FCC Class "A" / CE / KC / ErP |
| Network | |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Features | |
| Suitable for indoor use | Y |
| Wall mountable | Y |
| Heat dissipation (max) | 1085 BTU/h |
| Other features | |
