TP-Link IES206GPP network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
€152,44
TP-Link IES206GPP, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, Wall mountable
Availability: In Stock
Industrial-Grade Protection Built for Harsh EnvironmentsEnhanced Networking Stability and SecurityEasy Operation and Maintenance with Omada’s Free Cloud Management
| Management features | |
|---|---|
| Switch type | Managed |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | 1 |
| SFP module slots quantity | 1 |
| Network | |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1w,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3x |
| 10G support | N |
| Port mirroring | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Auto MDI/MDI-X | Y |
| Spanning tree protocol | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Auto-negotiation | Y |
| Data transmission | |
| Switching capacity | 12 Gbit/s |
| Forwarding rate | 8.93 Mpps |
| MAC address table | 8000 entries |
| Store-and-forward | Y |
| Jumbo frames support | Y |
| Jumbo frames | 15000 |
| Security | |
| DHCP features | DHCP client |
| IGMP snooping | Y |
| Multicast features | |
| Multicast support | Y |
| Design | |
| Rack mounting | Y |
| Product colour | Black |
| Wall mountable | Y |
| DIN rail mounting | Y |
| Performance | |
| Fanless | Y |
| Power | |
| Power source | DC/PoE |
| Redundant power supply (RPS) support | Y |
| DC input voltage | 12 - 57 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) type supported | PoE+,PoE++ (4PPoE) |
| Power over Ethernet plus (PoE+) ports quantity | 3 |
| Power over Ethernet 4PPoE (PoE++) ports quantity | 1 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 120 W |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Storage relative humidity (H-H) | 5 - 95 % |
| Weight & dimensions | |
| Width | 155 mm |
| Depth | 120 mm |
| Height | 60 mm |
| Packaging content | |
| Quick start guide | Y |
| Certificates | |
| Certification | FCC, CE, RoHS |
