APC Rack PDU, 9000 switched, 0U, 30A, 200V and 208V, 21 C13 and C15, 3 C19 and C21 sockets
(0 review)Add your review
€1302,74

APC Rack PDU, 9000 switched, 0U, 30A, 200V and 208V, 21 C13 and C15, 3 C19 and C21 sockets, Switched, 0U, Single-phase, Vertical, Black, 24 AC outlet(s)

Availability: In Stock
EAN:0731304356264Categories:PowerTags:

The APC Switched Rack PDU distributes reliable power within a rack through a single input and multiple output receptacles The APDU9941 offers advanced load management combined with remote on/off switching control of individual outlets for power cycling, delayed power sequencing, and outlet use management The 0U PDU includes a NEMA L6-30P input plug with 3 05m (10 ft) cord, (21) IEC 60320 C13/C15 and (3) IEC 60320 C19/C21 hybrid outlet receptacles The hybrid outlets allow 60°C operating temperature at full load, are compatible with standard C14 and C20 power cords, and are future-proofed for new C16 and C21 power cords required for higher temperature rated devices The Network Management Card provides enhanced cybersecurity with secured interfaces and modified password policy The rack PDU integrates with EcoStruxure IT through Network Management Card and can be accessed, configured, and managed remotely via Web, SNMP and Command Line Interface Color user-interactive LCD interface details current, real power, voltage, and energy measurements for local user access The outlet level control allows power on/off functionality for power recycling/reboot of remote equipment and restricts unauthorized use of individual outlets The Switched Rack PDU includes a temperature/humidity sensor port, locking IEC outlets when used with locking power cords, low-profile circuit breakers and USB port for local Firmware updates The rack PDU supports daisy-chain of up to 32 PDUs on a single IP address, thereby reducing networking cost The rack PDU comes with a standard three-year warranty

Design
PDU typesSwitched
TypeSingle-phase
Rack capacity0U
MountingVertical
Product colourBlack
Ports & interfaces
AC outlets quantity24 AC outlet(s)
Power plugNEMA L6-30P
AC outlet typesC13 coupler,C15 coupler,C19 coupler,C21 coupler
Ethernet LAN (RJ-45) ports1
Power
Nominal input voltage90 - 264 V
Maximum current30 A
Nominal output voltage200 - 208 V
Load capacity4992 VA
Certificates
Compliance certificatesRoHS
CertificationCUL , FCC 15 A, ICES-003, PSE
Sustainability
Sustainability complianceY
Operational conditions
Operating temperature (T-T)-5 - 60 °C
Storage temperature (T-T)-25 - 65 °C
Operating relative humidity (H-H)5 - 95 %
Operating altitude0 - 3048 m
Non-operating altitude0 - 15240 m
Weight & dimensions
Width55 mm
Depth46 mm
Height1829 mm
Weight8500 g
Packaging content
ManualY
Packaging data
Package weight10000 g
Package width165 mm
Package depth124 mm
Package height2040 mm
