be quiet! PURE BASE 501 Airflow Window Black Midi Tower
be quiet! PURE BASE 501 Airflow Window Black, Midi Tower, PC, Black, ATX, micro ATX, Mini-ITX, Acrylonitrile butadiene styrene (ABS), Steel, Tempered glass, 17.8 cm
Availability:: Arriving soon
Comfortably compactPure Base 501 Airflow Window Black is a traditional, timeless and versatile be quiet! ATX case with compact dimensions.REDUCED TO THE MAXClassic appearanceWithout any distractions, Pure Base 501 Airflow Window Black is reduced to excel at its core functions and is aimed at users that appreciate anunagitated presentation.PERFECT CASE FANFan blades optimized for high airflowWith optimization for maximum airflow, Pure Wings 3 140mm PWM is the perfect choice for Pure Base 501 Airflow Window Black. Its 7 airflow-optimized fan blades not only reduce noise-generating turbulences but also ensure Pure Wings 3 140mm PWM provides the performance that is needed for demanding configurations.MORE THAN MEETS THE EYEGenerous space for high-end hardwareDespite its compact dimensions, Pure Base 501 Airflow Window Black offers enough space for high-end graphics cards and large coolers. 3 fans or a radiator up to 360mm can be installed easily at the front, while the top area provides space for up to 2 fans or a radiator up to 240mm.WAY UP!With rotatable PCIe slotsWhy not try something else with your GPU? The PCIe slots of the Pure Base 501 Airflow Window Black can be rotated 90° for an upright installation of wide high-end graphics cards. The spacing is perfect for the optional be quiet! Riser Cable, whose foam base provides excellent anti-sag support for graphics cards in vertical orientation.INVENTORY MANAGEMENTWith smart cable routing optionsAs a compact PC case, Pure Base 501 Airflow Window Black optimally uses the offered space. Thanks to cleverly integrated cable routing options, it makes cable management a breeze.CONNECT WITH MEState-of-the-art technology for your systemA USB 3.2 Gen. 2 Type C connector and 2 Type A ports on the front I/O port for fast and easy connectivity.SHOW ME WHAT YOU'VE GOTA perfect view inside your PCThe high-quality, fully-windowed side panel offers a perfect view of the components inside your Pure Base 501 Airflow Window Black. The window is made of tinted and tempered glass with black painted side bars.
| Design | |
|---|---|
| Material | Acrylonitrile Butadiene Styrene (ABS),Steel,Tempered glass |
| Form factor | Midi Tower |
| Type | PC |
| Product colour | Black |
| Supported motherboard form factors | ATX,Micro ATX,Mini-ITX |
| Number of 3.5" bays | 2 |
| Number of 2.5" bays | 5 |
| Number of expansion slots | 7 |
| Side window | Y |
| Anti-dust filter | Y |
| Reset button | Y |
| On/off button | Y |
| Maximum CPU cooler height | 178 mm |
| Maximum PSU length | 180 mm |
| Power supply | |
| Power supply included | N |
| Supported power supply form factors | ATX,PS2 |
| Ports & interfaces | |
| Audio input | Y |
| Audio output | Y |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Cooling | |
| Front fans installed | 1x 140 mm |
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120,140 mm |
| Rear fans installed | 1x 140 mm |
| Number of rear fans supported (max) | 1 |
| Rear fans diameters supported | 120,140 mm |
| Number of top fans supported (max) | 2 |
| Top fans diameters supported | 120,140 mm |
| Maximum airflow | 57.4 cfm |
| Maximum air pressure | 0.96 mmH2O |
| Front radiator sizes supported | 120,140,240,280,360 mm |
| Rear radiator sizes supported | 120,140 mm |
| Top radiator sizes supported | 120,240 mm |
| Pulse-width modulation (PWM) support | Y |
| Storage | |
| Supported HDD sizes | 2.5,3.5 " |
| Technical details | |
| Compliance certificates | CE,REACH,RoHS,UKCA |
| Weight & dimensions | |
| Width | 231 mm |
| Depth | 450 mm |
| Height | 463 mm |
| Weight | 7200 g |
| Packaging data | |
| Package width | 292 mm |
| Package depth | 518 mm |
| Package height | 503 mm |
| Package weight | 8400 g |
