Rugged PoE Splitter | 12-48V DC | IP-30 Aluminum Housing | 1.5A Power OutputSplits a PoE connection (max 90W) into separate data (RJ45) and DC power (terminal block) that can power any device that uses DC power between 12V-48VDC (1.5A). Power non-PoE devices using network infrastructure, where power is not available.Power Non-PoE DevicesPerfect for using PoE to power older devices while also providing network access for monitoring and control applications. Applications include: Security (card swipe or proximity boxes) Environmental monitoring (temperature/moisture sensors) Telco (analog interface systems/conversion)Straightforward DeploymentSupports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), and IEEE 802.3bt (PoE++ / Type 3) PoE inputs up to 90W and splits data and power. Power output via terminal block can be configured for 12/16/24/48V DC (1.5A).The configuration is completed by DIP switches and the product can be wall or DIN rail mounted using the included hardware.Designed for Harsh EnvironmentsIndustrial features include -40 C to 75 C operating temperature, IP-30 rated housing, vibration, shock, and free-fall standard testing.Vibration: EN 60068-2-6Shock: EN 60068-2-27Free-Fall: EN 60068-2-32600,000+ hours MTBF rating using Telcordia/Bellcore at 50 C for long-term reliability.The POESLT1G48V is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage- HIGH POWER GIGABIT PoE SPLITTER: Power non-PoE devices using network infrastructure where power isn't available - Splits PoE connection (max 90W) into RJ45 data & DC power (terminal block)- 90W POE IEEE802.3bt: Supports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), IEEE 802.3bt (PoE++ / Type 3); power out configured w/ DIP switch for 12/16/24/48V DC (1.5A) via terminal block
