Neomounts WL30-750BL18P Heavy duty wall mount 50-98" - fixed - lockable - portrait - fast installation - TÜV
(0 review)Add your review
€61,20

Neomounts WL30-750BL18P Heavy duty wall mount 50-98" - fixed - lockable - portrait - fast installation - TÜV, 127 cm (50"), 2.49 m (98"), 100 x 100 mm, 500 x 800 mm, Steel, Black

Availability:: Arriving soon
EAN:8717371443290Categories:Monitors & Projectors

The Neomounts WL30-750BL18P LEVEL is the ultimate solution for securely portrait mounting an interactive or heavy weight display up to 98" with a maximum capacity of 100 kg. This heavy-duty wall mount features a high profile wall plate and is engineered for stability and precision, ensuring your screen is securely mounted even on uneven surfaces. The wall mount is designed to provide the sturdiest and most stable touch screen experience. The brackets of the WL30-750BL18P feature depth adjustable wall supports on the lower brackets for better weight distribution and maximum stability. The mount features individual adjustable brackets (10 mm) for securely adjusting the display height or levelling it. The LEVEL-750 wall mount has a profile depth of 4,2 cm and is suitable for screens that meet VESA hole pattern 100x100 to 500x800 mm. Its quickly connectable wall plate allows for multiple screen mounting, while a clever kickstand service position provides easy access to cables and connectors, ideal when mounting large displays in portrait. Additionally, the wall plate is designed with specific cut-outs for wall sockets and securing devices and cables. It features various perforated holes for easy tie-wrap cable fixing and provides space for cable storage, ensuring a clean and tidy finishing.The WL30-750BL18P includes an safe and practical pull & release system, allowing you to quickly attach and detach the display in a safe and secure manner. It is possible to lock the brackets using a padlock (not included) for extra screen security.For a simple and effective storage, an optionally available, AV-rack can be installed to the left or right side of the mount.

Mounting
Maximum weight capacity100 kg
Minimum screen size50 "
Number of displays supported1
Maximum weight capacity (per display)100 kg
Maximum screen size98 "
Minimum VESA mount100 x 100 mm
Maximum VESA mount500 x 800 mm
Panel mounting interface100 x 200,100 x 100,100 x 150,120 x 120,150 x 200,200 x 100,200 x 150,200 x 200,200 x 300,200 x 400,300 x 100,300 x 200,300 x 300,350 x 350,400 x 200,400 x 300,400 x 400,400 x 600,440 x 400,460 x 640,500 x 500,500 x 400 mm
Mounting typeWall
Ergonomics
Height adjustmentY
Height adjustment range0 - 10 mm
Cable managementY
TypeFixed
Distance to the wall (max)42 mm
Design
Product colourBlack
Housing materialSteel
Technical details
Country of originChina
LockablePadlock not included
Weight & dimensions
Width550 mm
Depth42 mm
Depth (max)42 mm
Height684 mm
Weight5100 g
Packaging data
Package width933 mm
Package depth90 mm
Package height209 mm
Package weight6700 g
Logistics data
Master (outer) case width951 mm
Master (outer) case length227 mm
Master (outer) case height288 mm
Master (outer) case gross weight21000 g
Master (outer) case net weight15300 g
Products per master (outer) case3 pc(s)
Harmonized System (HS) code7326909890
Products per pallet (EU)54 pc(s)
