APC GVSUPS20K0B4HS uninterruptible power supply (UPS) Double-conversion (Online) 20 kVA 20000 W
APC GVSUPS20K0B4HS, Double-conversion (Online), 20 kVA, 20000 W, Sine, 384 V, 480 V
Availability: In Stock
Parallel-redundant capablePower the connected equipment with multiple uninterruptible power supplies to increase system redundancyParallel-capacity capableIncreases total power capacity by using multiple uninterruptible power supplies simultaneously.Internal backfeed protectionIncreases system defense from power anomalies.Energy storage flexibilityConventional flooded and modular battery offer along with different charging modes allows tailoring to specific back-up requirements.Compatible with Schneider Electric's lithium ion battery solutionReduces system footprint and weight, cooling and maintenance requirements, and total cost of ownership; offers double the life of VRLA batteries; and improves backup storage predictability and manageability.Total cost of OwnershipRobust operationNo power derating in kW up to 40 degrees C or 104 degrees F.Input Power Factor CorrectionMinimizes installation costs by enabling the use of smaller generators and cabling.Wide input voltage rangeDesigned for harsh electrical environments to save battery life.ECOnversion modeOperating mode that ensures ultra high efficiency while charging the batteries, conditioning the load power factor and ensuring a Class 1 output voltage regulation.ECO ModeOperating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protectionServiceabilityFront-access servicingSimplifies installation and UPS maintenance while minimizing space requirements.Multiple levels of serviceWith the option of packages or individual service components, our services are structured to allow you to pick and choose what you would like APC to do for you.StruxureWare Data Center Expert compatibleEnables centralized management via StruxureWare Data Center Expert.StruxureOn enabledSimplify maintenance and operation of your equipment through the use of vendor-neutral, cloud-based software and services.5x8 Start-up service includedRequired for full coverage of factory warranty
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 20 kVA |
| Output power | 20000 W |
| Waveform | Sine |
| Input operation voltage (min) | 384 V |
| Input operation voltage (max) | 480 V |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 340 V |
| Output operation voltage (max) | 460 V |
| Output frequency | 50/60 Hz |
| Maximum current | 54 A |
| Number of input phases | 3 |
| Number of output phases | 3 |
| Power factor | 0.99 |
| Crest factor | 2.5:1 |
| ECO mode | Y |
| Output voltage Total Harmonic Distortion (THD) | 3 % |
| Input current Total Harmonic Distortion (THD) | 3 % |
| Noise level | 55 dB |
| Power protection features | Overload,Short circuit |
| Audible alarm(s) | Y |
| Ports & interfaces | |
| AC outlet types | Hard Wire 5-wire (3PH + N + G) |
| SmartSlot | Y |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 480 V |
| Design | |
| Form factor | Tower |
| Product colour | White |
| Display type | LED |
| International Protection (IP) code | IP20 |
| Compatibility | Schneider Electric's lithium ion battery solution |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating altitude | 0 - 1005.84 m |
| Non-operating altitude | 0 - 3048 m |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | IEC 62040-1-1, IEC 62040-2, OSHPD |
| Weight & dimensions | |
| Width | 521 mm |
| Depth | 847 mm |
| Height | 1485 mm |
| Weight | 200000 g |
| Packaging data | |
| Package width | 640 mm |
| Package depth | 990 mm |
| Package height | 1680 mm |
| Package weight | 200000 g |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
