Sony SRG-A40 8.5 MP Black 3840 x 2160 pixels 60 fps CMOS 25.4 / 2.5 mm (1 / 2.5")
Sony SRG-A40 8.5 MP Black 3840 x 2160 pixels 60 fps CMOS 25.4 / 2.5 mm (1 / 2.5")
€3418,96

Sony SRG-A40, 8.5 MP, CMOS, 4K Ultra HD, 3840 x 2160 pixels, 60 fps, 30x

Availability:: Arriving soon
EAN:4548736143388Categories:AV Equipment

SRG-A40 with PTZ Auto FramingRevolutionary PTZ Auto Framing technology powered by built-in AI analytics ensures high quality composed shots without operator.Shooting redefined. AI makes you free.A Camera that Automatically and Naturally Shoots Video for youWith the advanced PTZ Auto Framing feature, the camera automatically track the target in a comfortable viewing with smooth Pan-Tilt-Zoom movement regardless of posture, movement and what one is wearing.Since the camera does most of the work automatically, the operator can spend its time efficiently.PTZ Auto Framing with built-in AI analyticsThis camera harnesses powerful AI-powered video analytics that can automatically detect and track the position of a presenter within the camera frame. As the presenter moves, the camera’s pan/tilt/zoom mechanism ensures that the presenter is always framed naturally, without the need for a human camera operator to manually follow their movements.Automatically and reliably shoots video for youWith Sony’s newly developed AI analytics algorithm, it detects the subject’s skeleton and head position and matches the subject’s detail features even when there are several people in the frame. It achieves accurate framing and consistent tracking.Choice from three shooting modesThe camera has a choice of three shooting modes; Full body, Waist, and Close up. In each mode, you can adjust picture composition (size, up & down, and left & right) and the SRG-A40 and SRG-A12 can automatically track and keep the subject in the selected optimal position.Integrated tally lampThe SRG-A40 and SRG-A12 feature a built-in tally lamp, just like you’d find on professional studio cameras. The lamp illuminates to give presenters visual confirmation of shooting status, or to show that PTZ Auto Framing mode is active. The lamp colour will change from Red (On Air) to Green (PTZ Auto Framing ON).Remote control of PTZ operationPan/Tilt/Zoom camera movements and other functions can all be precisely controlled using the supplied IR remote controller, for convenient wireless control of PTZ functions without needing additional equipment. It can also be controlled using the optional additional RM-IP500 remote controller, just like professional broadcast cameras.Easy ceiling mountingThe camera comes supplied with a mounting plate for convenient ceiling installation if required.Light, compact designThe camera’s stylish, compact body fits unobtrusively into any environment.Choice of colour finishesThe camera is available in a choice of black or while colour finishes, to suit the needs of any application.

Camera
Camera typeSingle camera
Megapixel (approx.)8.5 MP
Sensor typeCMOS
Optical sensor size1/2.5 "
Zoom capabilityY
Optical zoom30 x
Focal length range4.4 - 88 mm
Horizontal field of view (wide)70 °
Minimum illumination1.6 lx
Flip & mirrorY
Aperture range (F-F)2 - 3.8
White balanceIndoor,One push,Outdoor,Auto,Manual,Daylight
Auto exposureY
Light exposure modesManual,Auto,Shutter priority AE
Focus adjustmentAuto/Manual
Gain control typeAuto/Manual
PTZ controlY
PTZ protocolsVISCA
Minimum working distance (wide)80 mm
Maximum working distance (tele)800 mm
Slowest camera shutter speed1 s
Fastest camera shutter speed1/10000 s
Video
HD type4K Ultra HD
Maximum video resolution3840 x 2160 pixels
Maximum frame rate60 fps
Video formats supportedH.264,H.265
Supported graphics resolutions3840 x 2160,1920 x 1080 (HD 1080),640 x 360,1280 x 720 (HD 720)
Number of TV lines1700
Design
Product colourBlack
Image stabilizerY
Tilt angle range-20 - 90 °
Pan range-170 - 170 °
Tally lightY
Tilt speed (min)0.5 °/sec
Tilt speed (max)126 °/sec
Pan speed (min)0.5 °/sec
Pan speed (max)300 °/sec
Ports & interfaces
HDMI ports quantity1
Ethernet LAN (RJ-45) ports1
DC-in jackY
3G-SDI outputY
Microphone inY
VISCA output ports1
VISCA input ports1
Power
Power source typeAC,DC
DC input voltage19.5 V
Power consumption (typical)80 W
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Packaging content
Power supply includedY
Cables includedAC,HDMI
Warranty cardY
Screws includedY
Mounting brackets includedY
System requirements
Windows operating systems supportedWindows 11 Enterprise x64,Windows 10,Windows 11 Home,Windows 10 Education,Windows 11 Pro,Windows 10 Education x64,Windows 11 x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 Enterprise
Mac operating systems supportedMac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey
Performance
Auto framingY
Audio
Audio channels2
Audio codecsAAC LC 256kbps/ST (IP), AAC LC 128kbps/ST(IP)
Network
Multi-stream capability3
Bit rate controlConstant Bit Rate (CBR),Variable Bit Rate (VBR)
Bit rate range512 - 50000 Kbit/s
Supported network protocolsIPv4, IPv6, TCP, UDP, ARP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP/RTCP, RTSP, VISCA over IP, SRT
Weight & dimensions
Width156.7 mm
Depth200 mm
Height184 mm
Weight2000 g
