TP-Link AV1000 Gigabit Passthrough Powerline Starter Kit
TP-Link AV1000 Gigabit Passthrough Powerline Starter Kit, 1000 Mbit/s, IEEE 1901, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, Type E / F, Gigabit Ethernet, 10,100,1000 Mbit/s, HomePlug AV2
Availability: In Stock
Gigabit Network Goes Furtherwith AV1000 PowerlineHomePlug AV2AV1000 Gigabit Passthrough Powerline Starter KitTL-PA7017P KIT1000 Mbps!Perfect for Bandwidth-Hungry ActivitiesComing with advanced HomePlug AV2 technology, TL-PA7017P KIT provides users with high-speed data transfer rates of up to 1000 Mbps—ideal for bandwidth-intensive applications such as multiple HD/3D/4K video streaming, online gaming, and large file transfers.Gigabit Port forUltra-Fast Data TransferWith one Gigabit Ethernet port, TL-PA7017P KIT allows users to connect a bandwidth-intensive device to the internet at high speeds, ensuring smooth streaming for Ultra HD videos. This makes the TL-PA7017P KIT the perfect home entertainment companion.Plug and Play, No Configuration RequiredConnect a powerline adapter to the router. Plug another powerline adapter into a wall socket in another room. Connect it to your internet enabled device via Ethernet—and you’re done!Extra Power Outlet for Additional DevicesFinding it hard to plug in your devices? The TL-PA7017P KIT has an integrated AC pass-through power socket. Your powerline adapter can now be used like a traditional electrical outlet. Plug your smart TV or game consoles into the adapter. No socket left to waste.Up to 85% Power SavedThe future’s looking green for powerline adapters. TL-PA7017P KIT’s practical design and sophisticated Power-Saving Mode, which automatically switches from its regular "Working" mode to "Power-Saving" mode, reduces its energy consumption by up to 85%
| Performance | |
|---|---|
| Maximum data transfer rate | 1000 Mbit/s |
| Ethernet LAN | Y |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | N |
| Networking standards | IEEE 1901,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Power plug | Type E / F |
| Built-in power socket | Y |
| PowerLine standard | HomePlug AV2 |
| Modulation | OFDM |
| Security algorithms | 128-bit AES |
| Maximum operating distance | 300 m |
| Encryption button | Y |
| Plug and Play | Y |
| Power | |
| Power consumption (typical) | 2.3 W |
| Power consumption (standby) | 0.5 W |
| Design | |
| LED indicators | LAN,PLC,Power |
| Product colour | White |
| Certification | CE |
| System requirements | |
| Windows operating systems supported | Windows 2000,Windows 7,Windows 8,Windows 8.1,Windows Vista,Windows XP |
| Linux operating systems supported | Y |
| Mac compatibility | Y |
| Mac operating systems supported | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 5 - 90 % |
| Weight & dimensions | |
| Width | 58 mm |
| Depth | 42 mm |
| Height | 95 mm |
| Certificates | |
| Compliance certificates | RoHS |
| Packaging data | |
| Package width | 190 mm |
| Package depth | 136 mm |
| Package height | 100 mm |
| Package weight | 580 g |
| Packaging content | |
| Quantity per pack | 2 pc(s) |
| Quick installation guide | Y |
| Cables included | LAN (RJ-45) |
| Logistics data | |
| Harmonized System (HS) code | 85171800 |
