APC GVSUPS10KB2HS uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W
APC GVSUPS10KB2HS, Double-conversion (Online), 10 kVA, 10000 W, Sine, 340 V, 460 V
Availability: In Stock
GVSUPS10KB2HS Features- Galaxy VS UPS 10kW 400V, 1 internal 7Ah smart modular battery string, expandable to 2, Start-up 5x8- Highly efficient, easy-to-deploy 10kW, 400V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Includes 5x8 start-up service and 1 smart high-capacity modular battery string, expandable to 2 strings for extended runtime.- Includes: Battery modules ship installed, Dust filter, EcoStruxure Ready ((UPS)), Installation guide, Integrated network management, Power modules ship installed, Start-Up Service
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 10 kVA |
| Output power | 10000 W |
| Waveform | Sine |
| Input operation voltage (min) | 340 V |
| Input operation voltage (max) | 460 V |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 415 V |
| Output frequency | 50/60 Hz |
| Maximum current | 18 A |
| Number of input phases | 3 |
| Number of output phases | 3 |
| Input power factor | 0.99 |
| Crest factor | 2.5:1 |
| ECO mode | Y |
| Output voltage Total Harmonic Distortion (THD) | 3 % |
| Input current Total Harmonic Distortion (THD) | 3 % |
| Noise level | 55 dB |
| Power protection features | Overload,Short circuit |
| Audible alarm(s) | Y |
| Ports & interfaces | |
| AC outlet types | Hard Wire 4-wire (3PH + G),Hard Wire 5-wire (3PH + N + G) |
| SmartSlot | Y |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 480 V |
| Design | |
| Form factor | Tower |
| Product colour | White |
| Display type | LCD |
| International Protection (IP) code | IP20 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage relative humidity (H-H) | 10 - 80 % |
| Operating altitude | 0 - 1000 m |
| Non-operating altitude | 0 - 3000 m |
| Certificates | |
| Certification | CSA C22.2 NO. 107.3, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, FCC Part 15 Class A, IEC 60721-4-2 Level 2M2, UL 1778 5th edition |
| Packaging content | |
| Quick installation guide | Y |
| Weight & dimensions | |
| Width | 333 mm |
| Depth | 847 mm |
| Height | 1485 mm |
| Weight | 245000 g |
| Packaging data | |
| Package width | 640 mm |
| Package depth | 990 mm |
| Package height | 1690 mm |
| Package weight | 270000 g |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
