TP-Link Gigabit Single-Mode WDM Bi-Directional SFP Module

(0 review)Add your review

€11,94

TP-Link Gigabit Single-Mode WDM Bi-Directional SFP Module, Fiber optic, 1250 Mbit/s, SFP, LC, 9/125 µm, BX

Availability: In Stock

Add to Cart

Add to wishlist

Compare

EAN:6935364072940Categories:NetworkingTags:

TP-LINK´s TL-SM321B adopts the latest standard 1000Base-BX, transmission over a single strand of fiber, with one different wavelength going in each direction. You can extend the network distance up to 10Km(6.2 miles) with TP-LINK´s Routers, Switches, Media Converters to provide high speed and stability.

Performance
SFP transceiver type	Fiber optic
Maximum data transfer rate	1250 Mbit/s
Interface type	SFP
Single-mode fiber (SMF) supported	Y
Multi-mode fiber (MMF) supported	N
Fiber optic connector	LC
Fiber cable diameters supported (core/cladding)	9/125 µm
SFP transceiver standard	BX
Maximum transfer distance	1000 m
Tx wavelength (max)	1310 nm
Rx wavelength (max)	1550 nm
Networking standards	IEEE 802.3z
Wavelength-division multiplexing (WDM)	Y
Features
Product colour	Metallic
Certificates
Compliance certificates	RoHS
Certification	FCC, CE
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 80 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Weight & dimensions
Width	55.4 mm
Depth	14.6 mm
Height	12.9 mm
Packaging content
Quantity per pack	1 pc(s)
Packaging data
User guide	Y
Package width	81.5 mm
Package depth	122.5 mm
Package height	38.5 mm
Package weight	60 g
Logistics data
Harmonized System (HS) code	85369010
