StarTech.com USB-C Triple Monitor Docking Station - HDMI/DP Triple 4k USB-C Dock - 5x USB Hub - GbE - 100W PD - Universal Multi Monitor Docking Station - Thunderbolt 3/4 Compatible
(0 review)Add your review
€181,51

StarTech.com USB-C Triple Monitor Docking Station - HDMI/DP Triple 4k USB-C Dock - 5x USB Hub - GbE - 100W PD - Universal Multi Monitor Docking Station - Thunderbolt 3/4 Compatible, Wired, USB 3.2 Gen 2 (3.1 Gen 2) Type-C, 100 W, 3.5 mm, 10BASE-T, 100BASE-TX, 1000BASE-T, IEEE 802.3ab

Availability:: Arriving soon
EAN:0065030900089Categories:Computers

Seamlessly standardize across platforms with triple 4K display supportThis USB-C Triple 4K Monitor Docking Station enables wide workstation flexibility, featuring compatibility with USB-C, or Thunderbolt 3/Thunderbolt 4 laptops, and supporting multiple combinations of Ultra HD 4K DisplayPort and HDMI monitors.Enhance Productivity with Triple-4K VideoThis triple-4K docking station uses a combination of its integrated DisplayLink® graphics controller and your computer's DP Alt Mode enabled USB-C port to provide three independent 4K displays.Connect any combination of HDMI and/or DisplayPort monitors to Video Ports 1 and 2 (DisplayLink®); at resolutions up to 4K at 60Hz. Connect an HDMI monitor to Video Port 3 (DP Alt-Mode), at resolutions up to 4K at 30Hz. This high-resolution video performance is ideal for detailed graphics applications, enhancing your productivity by expanding the display capabilities of your laptop.Full-Featured Docking StationConnect the docking station to your computer's USB 3.2 Gen 2 (10Gbps) Type-C port to provide a wide range of port connectivity, options and features. The docking station features:• 2x USB-A and 1x USB-C (USB 3.2 Gen 1 5Gbps) ports for USB peripheral devices.• 1x USB-A and 1x USB-C (USB 3.2 Gen 2 10Gbps) port that supports BC 1.2 with 7.5W (1.5A) for charging tablets and smartphones.• 1x Gigabit Ethernet port with WoL (Wake-on-LAN) for a wired Local Area Network (LAN) connection.• 1x 3.5mm 4-position TRRS Audio Jack for a 3.5mm headset.100W USB Power DeliveryThe USB-C docking station supports 100W USB Power Delivery with the included power adapter. This allows you to charge the connected host device, as well as the devices connected to the BC 1.2 USB charging ports.For added protection to connected USB devices, the BC 1.2 enabled USB charging ports feature Overcurrent Protection (OCP). OCP prevents USB peripherals from drawing more power than is safely allocated for the port.Easy DeploymentConnect the dock to your host computer, using the included 3.3ft (1m) USB-C cable. The docking station supports all major operating systems, including Windows, macOS, ChromeOS, and Ubuntu. This dock was designed for seamless integration with any compatible USB-C equipped device within your organization, including Lenovo X1/Thinkpad P Series, Dell Latitudes/Precision/XPS 15, HP Envy, Surface Laptop 3, and M1 Pro/Max/M2 MacBooks. The dock features a side-facing K-Slot for added security in shared workspaces (e.g., BYOD hoteling/hot-desking).Enhance Productivity and Device Management with the StarTech.com Connectivity Tools ApplicationDeveloped to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:•Advanced Windows Layout Utility : Setup and save custom windows layouts.•Mac Address Pass-Through Utility : Improve network security.•USB Event Monitoring Utility : Track and log connected USB devices.•Wi-Fi Auto Switch Utility : Enable users to quickly access faster network speeds via wired LAN.For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-ToolsThis product is backed for 3-years by StarTech.com, including free lifetime 24/5 multi-lingual technical assistance.

Ports & interfaces
Connectivity technologyWired
Host interfaceUSB 3.2 Gen 2 (3.1 Gen 2) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB Power Delivery (USB PD)Y
USB Power Delivery revision3.0
USB Power Delivery up to100 W
HDMI ports quantity3
HDMI version2.0
DisplayPorts quantity2
DisplayPort version1.4
Combo headphone/mic portY
Headphone outputs1
Headphone connectivity3.5 mm
USB Type-C DisplayPort Alternate ModeY
Network
Ethernet LANY
Ethernet LAN (RJ-45) ports1
Copper ethernet cabling technology10BASE-T,100BASE-TX,1000BASE-T
Wake-on-LAN readyY
Networking standardsIEEE 802.3ab
Performance
Card reader integratedN
Data transfer rate10 Gbit/s
HD type4K Ultra HD
Maximum digital resolution4096 x 2160 pixels
Maximum refresh rate60 Hz
Cable lock slotY
Cable lock slot typeKensington
Product colourGrey,Silver
LED indicatorsPower
Housing materialPlastic
Power
AC input voltage100 - 240 V
Input current2.5 A
Output voltage24 V
Output current5.41 A
Power consumption (typical)15 W
Power plug typeType M
Software
Windows operating systems supportedWindows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Mac operating systems supportedMac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.15.3 Catalina,Mac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey,Mac OS X 13.0 Ventura
Linux operating systems supportedY
Mobile operating systems supportedAndroid
Other operating systems supportedChromeOS
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)0 - 85 %
Weight & dimensions
Width85 mm
Depth190 mm
Height30 mm
Weight350 g
Packaging data
Package width205 mm
Package depth250 mm
Package height50 mm
Package weight1100 g
Packaging content
Cables includedAC,USB Type-C to USB Type-C
AC adapter includedY
Quick start guideY
Logistics data
Products per master (outer) case10 pc(s)
Master (outer) case width280 mm
Master (outer) case length430 mm
Master (outer) case height290 mm
Other features
ChipsetDisplayLink - DL-6950-N, VIA - VL817C0, Parade - PS176C0
