AOC AM420B monitor mount / stand 86.4 cm (34") Desk Black
AOC AM420B, Clamp/Bolt-through, 9 kg, 43.2 cm (17"), 86.4 cm (34"), 100 x 100 mm, Black
Availability:: Arriving soon
Enhance your workspace: the AM420B dual arm - Seamlessly integrate, maximize space, and manage cables.The AM420B is an embodiment of precision and strength. Crafted to perfection with an aluminum alloy build, the dual arm accommodates monitor sizes from 17” to 34”, with a maximum weight capacity of 9 kg. Its durable mechanical spring mechanism ensures sturdy support, while VESA compatibility (75x75, 100x100mm) allows for easy integration. Enjoy a versatile range of motion, including up to 495 mm height adjustment, up to 456 mm extension, -15°/90° tilt, -90°/90° swivel, and 360° pivot range, enhancing your workspace flexibility. Select between C Clamp or Grommet installation methods to suit your setup and elevate your ergonomic experience with the dual arm AM420B.
| Mounting | |
|---|---|
| Maximum weight capacity | 9 kg |
| Minimum screen size | 17 " |
| Number of displays supported | 2 |
| Maximum weight capacity (per display) | 9 kg |
| Maximum screen size | 34 " |
| Mounting | Clamp/Bolt-through |
| Mounting type | Desk |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Panel mounting interface | 100 x 100,75 x 75 mm |
| Desk thickness (min) | 15 mm |
| Desk thickness (max) | 50 mm |
| Clamp mount desk thickness (max) | 50 mm |
| Ergonomics | |
| Height adjustment | Y |
| Height adjustment type | Manual |
| Height adjustment range | 250 - 495 mm |
| Depth adjustment range | 0 - 455 mm |
| Tilt adjustment | Y |
| Tilt angle range | -15 - 90 ° |
| Swivelling | Y |
| Swivel angle range | -90 - 90 ° |
| Pivot angle | 0 - 360 ° |
| Number of arms | 2 |
| Cable management | Y |
| Design | |
| Housing material | Aluminium |
| Product colour | Black |
| Weight & dimensions | |
| Weight | 4600 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 322 mm |
| Package depth | 440 mm |
| Package height | 110 mm |
| Package weight | 5500 g |
| Package type | Box |
| Packaging content | |
| Clamp included | Y |
| Mounting kit | Y |
| Manual | Y |
| Packaging content | User Manual, Monitor Arm, Clamp mount, Grommet mount, Installation materials |
| Other features | |
| Height (max) | 495 mm |
| Warranty period | 5 year(s) |
