StarTech.com 2-port PCI Express RS232 Serial Adapter Card - PCIe RS232 Serial Host Controller Card - PCIe to Serial DB9 - 16950 UART - Low Profile Expansion Card - Windows & Linux
(0 review)Add your review
€44,22

StarTech.com 2-port PCI Express RS232 Serial Adapter Card - PCIe RS232 Serial Host Controller Card - PCIe to Serial DB9 - 16950 UART - Low Profile Expansion Card - Windows & Linux, Mini PCI Express, Serial, PCIe 1.1, RS-232, 222366 h, CE, FCC

Availability: In Stock
EAN:0065030881166Categories:NetworkingTags:

PCI Express to Serial Adapter | 921.4Kbps | Windows® and Linux® CompatibleThis RS232 Serial Adapter Card lets you add two RS232 (DB9) serial ports to your computer through a PCI Express (PCIe) slot. It enables you to interact with serial devices, such as card readers, printers, PIN pads, and modems, at speeds of up to 921.4Kbps.Maximum CompatibilityWith broad OS support, including for Windows and Linux, this PCI Express card is easy to integrate into mixed environments. The card comes pre-configured with a low-profile bracket, and includes an optional full-profile bracket, so installation is easy regardless of the case form factor.Experience Optimal TechnologyThis PCIe to serial adapter supports the following features:• Compatible with industry standard 16950 UART• Supports max baud rate of up-to 921.4Kbps• Provides 5/12V power output on Pin 9 when external power is connected• 256-byte depth FIFO per transmitter and receiver• Supports 9, 8, 7, 6, 5 data bits• Asix AX99100 chipset• PCI Express 1.1 compliantPEX2S953LP is backed by a StarTech.com lifetime warranty and free lifetime technical support.The StarTech.com Advantage

Ports & interfaces
Host interfaceMini PCI Express
Output interfaceSerial
Expansion card standardPCIe 1.1
Serial ports quantity2
Serial interface typeRS-232
Peripheral (Molex) power connectors (4-pin)1
Design
InternalY
Mean time between failures (MTBF)222366 h
CertificationCE, FCC
Features
ChipsetAsix AX99100
Baud rate921.6 Kbit/s
FIFO (First In, First Out)256 B
Data bits5,6,7,8,9
Stop bits1,1.5,2
Parity bitEven,Mark,N,Odd,Space
Flow Control typeN,RTS/CTS,XON/XOFF
Operational conditions
Operating temperature (T-T)-10 - 80 °C
Storage temperature (T-T)-20 - 100 °C
Operating relative humidity (H-H)5 - 85 %
System requirements
Windows operating systems supportedWindows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Linux operating systems supportedY
Server operating systems supportedWindows Server 2003,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016
Technical details
Compliance certificatesRoHS
Weight & dimensions
Width67 mm
Depth98 mm
Height18 mm
Weight55.6 g
Packaging data
Quantity1
Mounting brackets includedY
ManualY
Package width142 mm
Package depth172 mm
Package height32 mm
Package weight146.4 g
Logistics data
Harmonized System (HS) code84733020
Products per master (outer) case75 pc(s)
Master (outer) case width355 mm
Master (outer) case length690 mm
Master (outer) case height317 mm
