Lenovo 7ZT7A00537 network card Internal Fiber 10000 Mbit/s
Lenovo 7ZT7A00537, Internal, Wired, PCI Express, Fiber, 10000 Mbit/s, Black, Green
Availability: In Stock
The Intel X710 family of 10 Gigabit Ethernet (GbE) server network adapters addresses the demanding needs of the next-generation data center. By providing unmatched features for server and network virtualization, small packet performance, and low power; the data center network is flexible, scalable, and resilient.The X710 is available in three host connections: a standard PCIe host interface, a Mezzanine LOM (ML2) host interface for ThinkSystem and System x servers, and an AnyFabric host interface for ThinkServer systems.
| Ports & interfaces | |
|---|---|
| Connectivity technology | Wired |
| Host interface | PCI Express |
| Interface | Fiber |
| Fiber ports quantity | 2 |
| Fiber optic connector | SFP+ |
| Network | |
| Maximum data transfer rate | 10000 Mbit/s |
| Networking standards | IEEE 802.1Q,IEEE 802.1ad,IEEE 802.1as,IEEE 802.1p,IEEE 802.3ae,IEEE 802.3x |
| Wake-on-LAN ready | Y |
| Jumbo frames support | Y |
| Jumbo frames | 9728 |
| VLAN tagging | Y |
| iSCSI support | Y |
| Design | |
| Component for | Server |
| Product colour | Black,Green |
| Internal | Y |
| Certification | EN55022 EN55024 EN 61000-3-2 EN 61000-3-3 ICES-003, Issue-004 FCC 47 CFR Part 15 Class A VCCI AS/NZS CISPR 22 / C-tick RRL for KC BSMI UL 94 V-1 |
| System requirements | |
| Compatible operating systems | Microsoft Windows Server 2008 R2 Microsoft Windows Server 2012 Microsoft Windows Server 2012 R2 Microsoft Windows Server 2016 Red Hat Enterprise Linux 6 Server x64 Edition Red Hat Enterprise Linux 7 SUSE Linux Enterprise Server 11 for AMD64/EM64T SUSE Linux Enterprise Server 11 with Xen for AMD64/EM64T SUSE Linux Enterprise Server 12 SUSE Linux Enterprise Server 12 with XEN VMware vSphere 5.5 (ESXi) VMware vSphere 6.0 (ESXi) VMware vSphere 6.5 (ESXi) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -20 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage relative humidity (H-H) | 5 - 80 % |
| Operating altitude | 0 - 2134 m |
| Weight & dimensions | |
| Width | 15 mm |
| Depth | 167 mm |
| Height | 69 mm |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Other features | |
| Flow control support | Y |
| Intel® Virtualization Technology (Intel® VT) | Y |
| Intel Virtual Machine Device Queues (VMDq) | Y |
| Intelligent Offloads | Y |
| Intel Data Direct I/O Technology | Y |
| Receive Side Scaling (RSS) | Y |
