€47,81

NETGEAR GS305Pv3, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Wall mountable

EAN:606449164909Categories:NetworkingTags:

5-Port Switch Gigabit Unmanaged PoE switch with 4 PoE+ ports and 63W power budget to power Wireless AP, IP Cameras, IP Phones and more.

Management features
Switch type	Unmanaged
Quality of Service (QoS) support	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power connector	DC-in jack
Network
Networking standards	IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x
10G support	N
Full duplex	Y
Half duplex	Y
Flow control support	Y
Auto MDI/MDI-X	Y
Ethernet LAN data rates	10,100,1000 Mbit/s
Auto-sensing	Y
Data transmission
Switching capacity	10 Gbit/s
MAC address table	2000 entries
Jumbo frames support	Y
Jumbo frames	9216
Packet forwarding rate (1 Gbps)	1448000 pps
Packet buffer memory	0.128 MB
Design
Rack mounting	N
Stackable	N
Product colour	Black
LED indicators	Y
Wall mountable	Y
Performance
Mean time between failures (MTBF)	4113947 h
Power
Power source	DC
DC input voltage	54 V
Input current	1.25 A
Power consumption (max)	66.78 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	63 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Operating altitude	0 - 3000 m
Heat dissipation	228.38 BTU/h
Weight & dimensions
Width	158 mm
Depth	101 mm
Height	27 mm
Weight	400 g
