APC Symmetra LX 8kVA Scalable to 16kVA N+1 Rack-mount, 220/230/240V or 380/400/415V
€12704,68
APC Symmetra LX 8kVA Scalable to 16kVA N+1 Rack-mount, 220/230/240V or 380/400/415V, 8 kVA, 5600 W, IEC 60320, 7.5 min, 20.2 min, SYBT5
Availability: In Stock
High performance, redundant power protection with scalable power and runtime for space-constrained server rooms, and voice and data networks.
| Features | |
|---|---|
| Output power capacity | 8 kVA |
| Output power | 5600 W |
| Emergency Power Off (EPO) | Y |
| Audible alarm(s) | Y |
| Ports & interfaces | |
| AC outlet types | IEC 60320 |
| Battery | |
| Typical backup time at full load | 7.5 min |
| Typical backup time at half load | 20.2 min |
| Replacement battery cartridge | SYBT5 |
| Design | |
| Compatibility | C-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 55024, EN 60950, GOST, IEC 60950, VDE |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating altitude | 0 - 3000 m |
| Weight & dimensions | |
| Weight | 198640 g |
| Packaging data | |
| Package weight | 239550 g |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Total carbon footprint (kg of CO2e) | 30844.17 |
| Other features | |
| I/O ports | (1) Hard Wire 3-wire (H N + G) (8) IEC 320 C13 (10) IEC 320 C19 Hard Wire 3 wire (1PH+N+G) Hard Wire 5-wire (3PH + N + G) |
| Battery type | Lead-Acid |
| Interface | DB-9 RS-232, Smart-Slot |
| Output connections | (1) Hard Wire 3-wire (H N + G) (8) IEC 320 C13 (10) IEC 320 C19 |
| Input connection type | Hard Wire 3 wire (1PH+N+G) Hard Wire 5-wire (3PH + N + G) |
| Dimensions (WxDxH) | 472 x 688 x 838 mm |
| Nominal output voltage | 230 V |
| Output voltage note | 220: 230, 240 |
| Nominal input voltage | 230 V |
| Package dimensions (WxDxH) | 599 x 997 x 1054 mm |
