LevelOne Hilbert 8-Port Industrial Gigabit PoE Smart Lite Switch, 8 PoE Outputs, 802.3at/af PoE
LevelOne Hilbert 8-Port Industrial Gigabit PoE Smart Lite Switch, 8 PoE Outputs, 802.3at/af PoE, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE)
Availability: In Stock
The LevelOne IGS-2108P Hilbert 8-Port Industrial Gigabit PoE Smart Lite switch is a next-generation Ethernet Switch offering powerful better PoE functionality and usability that delivers the cost-effectively business and transports Ethernet services via copper connections. the IGS-2108P offers 8 (10M/100M/1G) RJ45, of which 8 are PoE+ (support 802.3at/af) ports to enable high speed network at mission-critical environment. With the industrial standard DIN-rail mount, plus the clearly visible status LEDs provide simple monitoring of port link activity.. can be matched with the latest LevelOne IP Locator, the software is the easiest to use switch discovery tool, it can search all Hilbert series switches, instantly know the forgotten IP and other info. Compatible with mainstream Windows and Mac operating systems.The LevelOne IGS-2108P provides high HW performance and environment flexibility for Enterprises. IGS-2108P is ideal to deliver management simplicity, optimum user experience, and lower total cost of ownership.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Network | |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Port mirroring | Y |
| Full duplex | Y |
| Half duplex | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Auto MDI/MDI-X | Y |
| Spanning tree protocol | Y |
| Auto-negotiation | Y |
| MAC address auto-learning supported | Y |
| MAC address auto-aging supported | Y |
| VLAN support | Y |
| Virtual LAN features | Port-based VLAN,Tagged VLAN |
| Number of VLANs | 32 |
| Data transmission | |
| Switching capacity | 16 |
| Forwarding rate | 11.904 |
| MAC address table | 4000 |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Packet buffer memory | 1.5 |
| Security | |
| IGMP snooping | Y |
| Queue scheduling algorithms | Priority queuing (PQ) |
| Multicast features | |
| Multicast support | Y |
| Design | |
| Stackable | N |
| Product colour | Black |
| LED indicators | Power,Link,Activity |
| Redundant fans support | Y |
| International Protection (IP) code | IP30 |
| DIN rail mounting | Y |
| Performance | |
| Flash memory | 2 |
| Noise level | 0 |
| Fanless | Y |
| Mean time between failures (MTBF) | 43800 |
| Power | |
| Power source | DC/PoE |
| Power supply included | N |
| Redundant power supply (RPS) support | Y |
| DC input voltage | 44 - 57 |
| Power consumption (typical) | 120 |
| Surge protection | Y |
| Surge protection voltage | 4 |
| Power protection features | Surge protection |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 112 |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 |
| Storage temperature (T-T) | -40 - 85 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 5 - 95 |
| Heat dissipation | 40.94 |
| Weight & dimensions | |
| Width | 153 |
| Depth | 114 |
| Height | 38 |
| Weight | 550 |
| Packaging content | |
| Quick start guide | Y |
| Packaging data | |
| Terminal block included | Y |
| Package type | Box |
| DIN rail included | Y |
| Package width | 230 |
| Package depth | 160 |
| Package height | 73 |
| Package weight | 780 |
| Sustainability | |
| Sustainability compliance | Y |
| Technical details | |
| Layers per pallet (air) | 16 |
| Pallet gross length | 800 |
| Pallet gross width | 1200 |
| Certificates | |
| Compliance certificates | CE,Federal Communications Commission (FCC),RoHS,UKCA |
| Logistics data | |
| Pallet gross height | 1544 |
| Country of origin | China |
| Master (outer) case width | 480 |
| Master (outer) case length | 395 |
| Master (outer) case height | 350 |
| Harmonized System (HS) code | 8517620090 |
| Master (outer) case gross weight | 16000 |
| Products per master (outer) case | 20 |
