LevelOne GTU-5211 network switch Unmanaged Gigabit Ethernet (10/100/1000) Black
LevelOne GTU-5211, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting
Availability: In Stock
Gigabit Speeds: Take Your Data to the Next LevelThe GTU-5211 is a 52-port Gigabit Ethernet Switch that gives you a high-performance, low-cost, easy-to-use, seamless upgrade to boost your network to 1000Mbps. Increase the speed of your network backbone to a massive 176Gbps and bring Gigabit speeds all the way to your computers.Bandwidth hungry? Not a problem.What happens when you have several users accessing multimedia applications all at the same time? No need to worry as GTU-5211 allows you to move large files faster and easier. Transfer your CGI, CAD, video, or other large multimedia files over the network instantly and without lag.Plug and Play, Flexible and EasyThe GTU-5211 is plug-and-play so no configuration is required. Providing auto MDI/MDI-X cable detection on all ports eliminates the need for crossover cables or Uplink ports. Each port can be used as general ports or Uplink ports, and any port can be simply plugged into a server, a hub, a router or a switch, using a straight cable or crossover cable. Diagnostic LEDs which display link status and activity, allowing you to quickly detect and correct problems on the network.
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 48 |
| Installed SFP+ modules quantity | 4 |
| Power connector | AC-in jack |
| Network | |
| Networking standards | IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| 10G support | Y |
| Full duplex | Y |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| MAC address auto-learning supported | Y |
| MAC address auto-aging supported | Y |
| Data transmission | |
| Switching capacity | 176 |
| MAC address table | 32000 |
| Jumbo frames support | Y |
| Jumbo frames | 10000 |
| Packet buffer memory | 16 |
| Design | |
| Rack mounting | Y |
| Stackable | N |
| Product colour | Black |
| LED indicators | Activity,Link,Power |
| Performance | |
| Internal memory | 256 |
| Flash memory | 16 |
| Noise level | 30 |
| Fanless | N |
| Power | |
| Power source | AC |
| Power supply included | Y |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Power consumption (typical) | 48 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | N |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 |
| Storage temperature (T-T) | -40 - 70 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 5 - 95 |
| Heat dissipation | 163.8 |
| Weight & dimensions | |
| Width | 440 |
| Depth | 290 |
| Height | 44.5 |
| Weight | 3389 |
| Packaging content | |
| Cables included | AC |
| Quick start guide | Y |
| Rack mount kit | Y |
| Packaging data | |
| Package type | Box |
| Package width | 515 |
| Package depth | 380 |
| Package height | 93 |
| Package weight | 4000 |
| Certificates | |
| Certification | CE, UKCA, FCC Part 15, Subpart B Class B, RoHS |
