LevelOne Hilbert 10” 16-Port Gigabit Smart Lite Switch, 16 x Gigabit RJ45 (10/100/1000)

€98,43

LevelOne Hilbert 10” 16-Port Gigabit Smart Lite Switch, 16 x Gigabit RJ45 (10/100/1000), Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting

Availability:: In stock

Add to Cart

Add to wishlist

Compare

EAN:4015867229989Categories:Networking

If you're in search of a networking solution that fits your 10-inch rack/enclosure, the LevelOne GES-2216 Hilbert gigabit smart lite switch is an excellent option. This next-generation Ethernet switch delivers better functionality and usability, making it cost-effective for businesses and organizations.The switch offers 16 (10M/100M/1G) RJ45 ports and is compatible with the latest LevelOne IP Locator, the easiest-to-use switch discovery tool, which can search all Hilbert series switches and instantly know forgotten IP and other info. Additionally, it's compatible with mainstream Windows and Mac operating systems.With both dumb and smart Switchable usage modes, the switch is easily configurable using a DIP switch. It provides high-speed connectivity for all your devices, with 16 Gigabit ports. The support for 802.1q VLAN allows you to segment your network for enhanced security and performance.The switch supports Port Mirroring, which allows you to monitor network traffic in real-time. Additionally, with Port-Based/802.1p/DSCP priority QoS and support for Storm Control, you can prioritize network traffic correctly and ensure that your network remains secure.The advanced features like Loop Detection/Prevention make sure your network is always safe and reliable. Moreover, the web-based user interface and Smart-Configuration Utility make IP configuration a breeze. Upgrade your networking today with this powerful switch, and enjoy the ultimate performance, security, and ease of use.

Management features
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	16
Power connector	AC-in jack
Network
Networking standards	IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support	N
Port mirroring	Y
Full duplex	Y
Half duplex	Y
Link aggregation	Y
Broadcast storm control	Y
Rate limiting	Y
Auto MDI/MDI-X	Y
Auto-negotiation	Y
MAC address auto-learning supported	Y
MAC address auto-aging supported	Y
VLAN support	Y
Number of VLANs	32
Data transmission
Switching capacity	32
Forwarding rate	23808
MAC address table	8000
Jumbo frames support	Y
Jumbo frames	10000
Packet buffer memory	4.1
Security
IGMP snooping	Y
Design
Rack mounting	Y
Stackable	N
Product colour	Black
LED indicators	Activity,Link,Power
Performance
Flash memory	2
Noise level	0
Fanless	Y
Mean time between failures (MTBF)	43800
Power
Power source	AC
Power supply included	Y
Power consumption (typical)	6
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
Operational conditions
Operating temperature (T-T)	0 - 45
Storage temperature (T-T)	-40 - 70
Operating relative humidity (H-H)	10 - 90
Storage relative humidity (H-H)	5 - 95
Heat dissipation	35.8
Weight & dimensions
Width	215
Depth	150
Height	44.5
Weight	838
Packaging content
Cables included	AC
Quick start guide	Y
Rack mount kit	Y
Packaging data
Package type	Box
Package width	285
Package depth	257
Package height	62
Package weight	1273
Certificates
Certification	CE, UKCA, FCC Part 15, Subpart B Class B, RoHS
