LevelOne Hilbert 28-Port Gigabit Smart Lite Switch, 24 x Gigabit RJ45, 4 x Gigabit SFP/RJ45 Combo

€170,67

LevelOne Hilbert 28-Port Gigabit Smart Lite Switch, 24 x Gigabit RJ45, 4 x Gigabit SFP/RJ45 Combo, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting

Availability:: In stock

Add to Cart

Add to wishlist

Compare

EAN:4015867229286Categories:Networking

The LevelOne GES-2128 Hilbert gigabit smart lite switch is a next-generation Ethernet Switch offering powerful better functionality and usability that delivers the cost-effectively business and transports Ethernet services via fiber or copper connections. GES-2128 delivers 24 (10M/100M/1G) RJ45 ports and 4 Combo GbE RJ45/SFP ports. can be matched with the latest LevelOne IP Locator, the software is the easiest to use switch discovery tool, it can search all Hilbert series switches, instantly know the forgotten IP and other info. Compatible with mainstream Windows and Mac operating systems.The LevelOne GES-2128 provides high HW performance and environment flexibility for Enterprises. GES-2128 is ideal to deliver management simplicity, optimum user experience, and lower total cost of ownership.

Management features
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	24
Combo SFP ports quantity	4
Network
Networking standards	IEEE 802.1Q,IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support	N
Copper ethernet cabling technology	10BASE-T,100BASE-TX,1000BASE-T
Port mirroring	Y
Full duplex	Y
Flow control support	Y
Link aggregation	Y
Broadcast storm control	Y
Rate limiting	Y
MAC address auto-learning supported	Y
MAC address auto-aging supported	Y
VLAN support	Y
Virtual LAN features	Tagged VLAN
Number of VLANs	32
Data transmission
Switching capacity	56
MAC address table	8000
Number of queues	4
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	4.1
Security
IGMP snooping	Y
Multicast features
Multicast support	Y
Design
Rack mounting	Y
Product colour	Black
LED indicators	Activity,Link,Power,System
Performance
Flash memory	2
Noise level	0
Fanless	Y
Mean time between failures (MTBF)	43800
Power
Power source	AC
AC input voltage	100 - 240
AC input frequency	50 - 60
Power consumption (max)	20
Surge protection	Y
Surge protection voltage	8
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
Operational conditions
Operating temperature (T-T)	0 - 45
Storage temperature (T-T)	-40 - 70
Operating relative humidity (H-H)	10 - 90
Storage relative humidity (H-H)	5 - 95
Heat dissipation	68.24
Weight & dimensions
Width	440
Depth	190
Height	44.5
Weight	1950
Packaging content
Cables included	AC
Quick start guide	Y
Rack mount kit	Y
Packaging data
Package type	Box
Package width	503
Package depth	270
Package height	85
Package weight	2550
Sustainability
Sustainability compliance	Y
Technical details
Master (outer) cases per pallet (air)	20
Pallet gross length	800
Pallet gross width	1200
Pallet height (air)	1594
Certificates
Compliance certificates	CE,RoHS
Certification	UKCA, FCC Class A
Logistics data
Master (outer) case net weight	750
Country of origin	China
Master (outer) case width	515
Master (outer) case length	360
Master (outer) case height	290
Master (outer) case gross weight	10950
Products per master (outer) case	4
