TP-Link Omada AX3000 Ceiling Mount WiFi 6 Access Point
TP-Link Omada AX3000 Ceiling Mount WiFi 6 Access Point, 2.4 GHz, 5 GHz, 2976 Mbit/s, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3-Enterprise,..., 10,100,1000 Mbit/s
Availability: Arriving Soon
The New Slimline Business WiFi 6AX3000 Ceiling Mount WiFi 6 Access PointAX3000 WiFi 6 Speed2402 Mbps on 5 GHz +574 Mbps on 2.4 GHz† High-Efficiency WiFi 6More connected devices can enjoy faster speeds Centralized Cloud ManagementManage the whole network locally or from the cloud 160 MHz ChannelDouble the data at peak transmission times on a single stream with HE160‡ Auto Channel Selection and Power Adjustment*Optimize overall performance by reducing WiFi interference Omada Mesh TechnologyMore flexible and convenient wireless deployment Seamless RoamingUninterrupted streaming when moving between APsUltra-Slim DesignΦ160 mm × 33.6 mm elegant design brings more agilityPoE+ PoweredSupports both DC (adapter included) and 802.3at PoE+ for flexible installationsSeamless Integration into Omada SDNThe Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers. It provides 100% centralized cloud management and creates a highly scalable network controlled from a single interface.Auto Channel Selection and Power Adjustmentto Optimize Overall PerformanceProvides powerful wireless performance while significantly reducing WiFi interference by automatically adjusting the channel settings and transmission power levels of neighboring APs in the same network.Easy Deployment & Higher Performance by Omada MeshEasy Pairing, Less WiringWith Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.Optimized Network PerformanceIntelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.Always Stay Smooth with Fast RoamingEnsures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.Ultra-Slim Design Brings More AgilityExceptional performance with compact design ensures simple WiFi installation while saving space. The elegant appearance makes EAP650 perfectly blend into any modern office, hotel, classroom, or café.
| Features | |
|---|---|
| 2.4 GHz | Y |
| 5 GHz | Y |
| 6 GHz | N |
| Maximum data transfer rate | 2976 |
| Maximum data transfer rate (2.4 GHz) | 574 |
| Maximum data transfer rate (5 GHz) | 2402 |
| Ethernet LAN data rates | 10,100,1000 |
| Frequency band | 2.4 - 5 |
| Networking standards | IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.1x,IEEE 802.3at |
| Cabling technology | 10/100/1000Base-T(X) |
| Number of users | 250 |
| Automatic channel selection | Y |
| Automatic channel scanning | Y |
| MIMO | Y |
| MIMO type | Multi User MIMO |
| Spread spectrum method | OFDMA |
| Fit AP mode features | Mesh networking |
| VLAN support | Y |
| Rate limiting | Y |
| Flow control support | Y |
| Band steering | Y |
| Airtime Fairness (ATF) | Y |
| Quality of Service (QoS) support | Y |
| BeamForming | Y |
| Transmitting power (CE) | <20 dBm(2.4 GHz, EIRP) <23 dBm(5 GHz, Band1 & Band2, EIRP) <30 dBm(5 GHz, Band3, EIRP) |
| Transmitting power (FCC) | <25 dBm (2.4 GHz) <25 dBm (5 GHz) |
| Security | |
| Security algorithms | SNMP,SNMPv2,SNMPv3,SSH,WPA-Enterprise,WPA-PSK,WPA2-Enterprise,WPA2-PSK,WPA3-Enterprise,WPA3-PSK |
| MAC address filtering | Y |
| Access Control List (ACL) | Y |
| Management features | |
| Web-based management | Y |
| Syslog | Y |
| Firmware upgradeable | Y |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Y |
| Power | |
| Power over Ethernet (PoE) | Y |
| DC voltage range | 12 |
| Design | |
| Placement | Ceiling,Wall |
| Product colour | White |
| Reset button | Y |
| LED indicators | Y |
| Antenna | |
| Antenna type | Internal |
| Certificates | |
| Certification | CE, FCC, RoHS |
| Weight & dimensions | |
| Width | 160 |
| Depth | 160 |
| Height | 33.6 |
| Packaging data | |
| Package type | Box |
| Packaging content | |
| Quantity per pack | 1 |
| Mounting kit | Y |
| Quick start guide | Y |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90 |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -40 - 70 |
| Storage relative humidity (H-H) | 5 - 90 |
