TP-Link 8-Port Gigabit Desktop PoE Switch with 4-Port

€38,45

TP-Link 8-Port Gigabit Desktop PoE Switch with 4-Port, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)

Availability: In Stock

Add to Cart

Add to wishlist

Compare

EAN:6935364021160Categories:NetworkingTags:

PoE Switches for Your Ultra Convenience8-Port Gigabit Desktop Switch with 4-Port PoEPower over Ethernet4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).Intelligent Power ManagementWhen total power consumption excels 55W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.Sturdy Metal CasingSturdy, compact metal casing and shielded RJ45 ports, with desktop, to meet your needs in any environment. Besides, fanless design ensures quiet operation.

Management features
Switch type	Managed
Quality of Service (QoS) support	N
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	8
Power connector	DC-in jack
Network
Networking standards	IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x
10G support	N
Copper ethernet cabling technology	1000BASE-T,100BASE-TX,10BASE-T
Cable types supported	Cat3,Cat4,Cat5,Cat5e
Flow control support	Y
Auto MDI/MDI-X	Y
Auto-negotiation	Y
MAC address auto-learning supported	Y
MAC address auto-aging supported	Y
Data transmission
Switching capacity	16 Gbit/s
Forwarding rate	11.904 Mpps
MAC address table	4000 entries
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	16000
Security
IGMP snooping	Y
Design
Rack mounting	N
Stackable	N
Product colour	Grey
Housing material	Metal
LED indicators	Y
Performance
Maximum cable length	100 m
Fanless	Y
Power
Power source	DC/PoE
Power supply included	Y
Number of power supply units	1
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
DC input voltage	53.5 V
Input current	1.31 A
Power consumption (max)	75 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	4
Total Power over Ethernet (PoE) budget	64 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Storage relative humidity (H-H)	5 - 90 %
Heat dissipation	225.75 BTU/h
Weight & dimensions
Width	171 mm
Depth	98 mm
Height	27 mm
Packaging content
Cables included	AC
User guide	Y
Packaging data
Package type	Box
Package width	223 mm
Package depth	280 mm
Package height	68 mm
Package weight	900 g
Sustainability
Sustainability compliance	Y
Certificates
Compliance certificates	CE,Federal Communications Commission (FCC),RoHS
