Neomounts PLASMA-C100 Monitor/TV mount ceiling 37-75" - h 67-107 cm

€227,68

Neomounts PLASMA-C100 Monitor/TV mount ceiling 37-75" - h 67-107 cm, 200 x 200 mm, 800 x 450 mm, 0 - 25°, 0 - 60°, Steel, Silver

Availability:: Arriving soon

Add to Cart

Add to wishlist

Compare

EAN:8717371441067Categories:Monitors & Projectors

The Neomounts ceiling mount, model PLASMA-C100 is a tilt- and swivel ceiling mount for flat screens up to 75" (191 cm). This mount is a great choice for space saving placement or when wall mounting and floor placement is not an option.Neomounts versatile tilt (25°) and swivel (60°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The support is easily height adjustable from 67 to 107 centimetres. If different heights are needed extension poles are available. An innovative cable management conceals and routes cables from ceiling to TV. Hide your cables in the column to keep it nice and tidy.Neomounts PLASMA-C100 has one pivot point and is suitable for screens up to 75" (191 cm). The weight capacity of this product is 50 kg. The ceiling mount is suitable for screens that meetVESA hole pattern 200x200 to 800x450mm. Different hole patterns can be covered using Neomounts VESA adapter plates.All installation material is included with the product.

Mounting
Maximum weight capacity	50 kg
Minimum screen size	37 "
Number of displays supported	1
Maximum weight capacity (per display)	50 kg
Maximum screen size	75 "
Minimum VESA mount	200 x 200 mm
Maximum VESA mount	800 x 450 mm
Panel mounting interface	200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400,440 x 400,500 x 400,600 x 300,600 x 200,600 x 400,680 x 300,800 x 200,800 x 400 mm
Mounting type	Ceiling
Ergonomics
Height adjustment	Y
Height adjustment type	Manual
Height adjustment range	670 - 1070 mm
Tilt adjustment	Y
Tilt angle range	0 - 25 °
Swivelling	Y
Swivel angle	60 °
Swivel angle range	0 - 60 °
Tilt angle	25 °
Distance to the wall (min)	78 mm
Design
Product colour	Silver
Housing material	Steel
Technical details
Country of origin	Taiwan
Weight & dimensions
Depth	80 mm
Height	1070 mm
Weight	16570 g
Packaging data
Package width	880 mm
Package depth	260 mm
Package height	280 mm
Package weight	17500 g
Logistics data
Master (outer) case width	880 mm
Master (outer) case length	260 mm
Master (outer) case height	280 mm
Master (outer) case gross weight	18300 g
Master (outer) case net weight	17500 g
Products per master (outer) case	1 pc(s)
Harmonized System (HS) code	7326909890
Products per pallet (EU)	21 pc(s)
Other features
Depth adjustment range	0 - 80 mm
