TP-Link PoE+ Injector
TP-Link PoE+ Injector, Gigabit Ethernet, 10,100,1000 Mbit/s, 10/100/1000, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, Cat3, Cat4, Cat5, Cat5e, Black
Availability: In Stock
The PoE+ Injector TL-POE160S fully complies with IEEE 802.3af/at standards, and can work with all IEEE 802.3af/at PoE compliant PDs (Powered Devices) or PoE Receiver Adapters, such as TP-Link's TL-POE10R, or other equivalent product, to expand your network to where there are no power line or outlet, where you wish to fix device such as AP, IP Camera or IP Phone, etc.
| Network | |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000 |
| Power over Ethernet (PoE) | Y |
| Networking standards | IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u |
| Cable types supported | Cat3,Cat4,Cat5,Cat5e |
| Features | |
| Product colour | Black |
| Wall mountable | Y |
| Plug and Play | Y |
| Maximum operating distance | 100 m |
| LED indicators | Power |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Power | |
| Output power | 30 W |
| AC adapter input voltage | 100 - 240 V |
| AC adapter frequency | 50/60 Hz |
| Certificates | |
| Certification | FCC, CE, RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Weight & dimensions | |
| Width | 125 mm |
| Depth | 59.4 mm |
| Height | 36.8 mm |
| Packaging content | |
| Number of products included | 1 pc(s) |
| Wall mounting kit | Y |
| Power cord included | Y |
| Quick installation guide | Y |
| Packaging data | |
| Package width | 170 mm |
| Package depth | 230 mm |
| Package height | 80 mm |
| Package weight | 460 g |
| Package type | Box |
| Logistics data | |
| Harmonized System (HS) code | 85044095 |
