be quiet! SFX L Power power supply unit 600 W 20+4 pin ATX Black
(0 review)Add your review
€109,07

be quiet! SFX L Power, 600 W, 100 - 240 V, 650 W, 50 - 60 Hz, 10 A, Active

Availability: In Stock
EAN:4260052187135Categories:PowerTags:

Compact and Silent Energybe quiet! SFX L Power 600W is especially recommended for mini ITX PCs and compact gaming systems. It performs well beyond the ordinary, with a great combination of quietness, features, reliability and efficiency.POWERFUL, RELIABLE AND STABLEA strong partner for Mini ITX and compact gaming PCsThe SFX L Power supplies CPUs and GPUs with steady and dependable power thanks to a stable 12V-rail, high quality Japanese capacitors and innovative technologies such as LLC, Synchronous Rectifier and DC-to-DC conversion. 4 PCIe connectors to support multi-GPU setups.QUIET OPERATION FOR COMPACT SYSTEMSOptimized for low-noise operationThis PSU is perfect for compact gaming PC or HTPC users who are looking for an SFX PSU that is fitted with a 120mm fan. This model includes a temperature-controlled fan. The SFX L Power was built to be very silent thanks to the fan technology used and it produces little wasted heat.80 PLUS® GOLD CERTIFICATIONVery high operating efficiencySFX L Power 600W is certified 80 PLUS Gold with an efficiency rating of up to 92% – a truly outstanding level for this class of PSU. The most compelling benefit: lower power consumption and consequently lower costs with cooler and quieter operation.MODULAR AND FLAT CABLESHighly compatible and convenientEntirely modular cables are enhanced by premium black flat cables. This simplifies the installation and keeps the system tidy.SUPER VERSATILE INSTALLATIONAdapts to your individual requirementsThis power supply is particularly versatile in deployment thanks to the SFX-to-ATX adapter bracket provided. Not only does it fit into cases with an SFX form factor, but can also be installed in a few simple steps into larger ATX cases.

Power
Total power600 W
Peak power650 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current10 A
Power factor0.99
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)110 W
Combined power (+12V)600 W
Combined power (+5V)110 W
Combined power (-12V)3.6 W
Combined power (+5Vsb)15 W
Max output current (+3.3V)22 A
Max output current (+12V)50 A
Max output current (+5V)22 A
Max output current (-12V)0.3 A
Max output current (+5Vsb)3 A
Hold time16.8 ms
Efficiency92 %
Power protection featuresOver current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Ports & interfaces
Motherboard power connector20+4 pin ATX
Motherboard power cable length300 mm
Number of SATA power connectors6
Number of PATA power connectors3
PCI Express power connectors (6+2 pin)4
PCI Express power cable length400 mm
CPU power connector (4+4 pin)Y
CPU power cable length400 mm
Cabling typeFully-Modular
Performance
80 PLUS certification80 PLUS Gold
Supported motherboard form factorsMini-ITX
PurposePC
Power supply unit (PSU) form factorSFX
ATX version2.4
Silent modeY
Bearing technologySleeve
Design
Product colourBlack
Fan diameter120 mm
Number of fans1 fan(s)
On/off switchY
Certificates
Compliance certificatesRoHS
CertificationCE, CB, TÜV, FCC, cTUVus, RCM
Weight & dimensions
Width125 mm
Depth130 mm
Height64 mm
Weight1160 g
Packaging data
ManualY
Package width205 mm
Package depth220 mm
Package height80 mm
Package weight2040 g
Package typeBox
Technical details
Sustainability certificatesENERGY STAR
Logistics data
Master (outer) case width430 mm
Master (outer) case length430 mm
Master (outer) case height240 mm
Master (outer) case gross weight21500 g
Harmonized System (HS) code84733020
Products per master (outer) case10 pc(s)
Other features
Screws includedY
Cable ties includedY
Noise level (silent mode, <30%)9.9 dB
Noise level (quiet mode, 50%)14.5 dB
Noise level (full-load mode, 100%)28.7 dB
