be quiet! Pure Power 13 M | 850W power supply unit 20+4 pin ATX ATX Black
be quiet! Pure Power 13 M | 850W, 850 W, 100 - 240 V, 900 W, 50/60 Hz, 12 A, 6 A
Availability: Arriving Soon
Exceptional quiet, superior featuresPure Power 13 M 850W is an ATX 3.1 compliant and PCIe 5.1 compatible power supply with semi-passive cooling. It offers peerless dependability with best-in-class features. Having both a PCIe 5.1 cable and PCIe 6+2 cables in the scope of delivery, this PSU offers outstanding compatibility with current-gen and next-gen graphics cards. Pure Power 13 M 850W offers the best combination of features with outstanding compatibility.
| Power | |
|---|---|
| Total power | 850 W |
| Peak power | 900 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Maximum input current (@110V) | 12 A |
| Maximum input current (@220V) | 6 A |
| Power factor | 0.98 |
| Power Factor Correction (PFC) type | Active |
| Number of +12V rail(s) | 1 |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 850 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 22 A |
| Max output current (+12V1) | 70.9 A |
| Max output current (+5V) | 22 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Hold time | 25.09 ms |
| Efficiency | 92.8 % |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit,Surge & inrush protection (SIP),Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 550 mm |
| Number of SATA power connectors | 6 |
| SATA power cable length | 500,650,800,950 mm |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| Peripheral (Molex) power cable length | 800,950 mm |
| EPS power connector (8-pin) | Y |
| PCI Express power connectors (6+2 pin) | 4 |
| PCI Express power connectors (12-pin) | 1 |
| CPU P4 connector (4-pin) | 2 |
| CPU power connector (4+4 pin) | Y |
| CPU power cable length | 650 mm |
| Cabling type | Fully-Modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| EPS version | 2.92 |
| Noise level | 30.2 dB |
| Bearing technology | Rifle |
| Mean time between failures (MTBF) | 100000 h |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 120 mm |
| Number of fans | 1 fan(s) |
| Fan speed | 0 - 2000 RPM |
| On/off switch | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Packaging content | |
| Cables included | AC,CPU,PCIe,Peripheral (Molex),SATA |
| Certificates | |
| Compliance certificates | BSMI,CB,CCC,CE,Federal Communications Commission (FCC),IRAM,RCM,RoHS,TÜV mark,UKCA,WEEE,cTUVus |
| Weight & dimensions | |
| Width | 150 mm |
| Depth | 160 mm |
| Height | 86 mm |
| Weight | 2620 g |
| Packaging data | |
| Package width | 210 mm |
| Package depth | 320 mm |
| Package height | 133 mm |
| Package weight | 3400 g |
| Technical details | |
| Sustainability certificates | ENERGY STAR,ErP |
| Logistics data | |
| Shipping (inner) case length | 580 mm |
| Shipping (inner) case width | 325 mm |
| Shipping (inner) case height | 233 mm |
| Products per shipping (inner) case | 6 pc(s) |
| Shipping (inner) case gross weight | 22700 g |
| Other features | |
| Screws included | Y |
| Cable ties included | Y |
