MSI MAG A650GL power supply unit 650 W 20+4 pin ATX ATX Black
(0 review)Add your review
€79,39

MSI MAG A650GL, 650 W, 100 - 240 V, 10 A, 5 A, Active, 100 W

Availability: In Stock
EAN:4711377084277Categories:PowerTags:

The MAG series fights alongside gamers in pursuit of honor.With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.80 PLUS GOLD CERTIFIEDThe efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS Gold certification promises lower energy consumption and higher efficiency.COMPACT SIZINGSmaller than typical PSUs on the market, this power supply unit that can save space and make it easier to organize cables in the computer case by freeing up more room inside.ONLY WHAT YOU NEEDThe connectors that required by the build need to be used, significantly reducing cable clutter and simplifying the system’s overall build. Additionally, the included cable pack provides a storage solution for any unused cables.ALL THE MORE ORGANIZEDOrganizing cables is often the most bothersome part of building a PC. The flat cables make cable management easier and less of headache! Thanks to the flat cables, the entire system can be more organized and has more room for unobstructed airflow.FLUID DYNAMIC BEARINGThe power supply’s fan sports a fluid dynamic bearing that perfectly balances cooling performance and noise level.DC TO DC & FULL BRIDGEDC to DC and Full bridge be combined to achieve higher conversion efficiency, stable output voltage, and quick voltage adjustment for different usage scenarios, thus providing a stable power supply design.THE POWER YOU HAVEThe single rail supply of power can properly deliver the power you need. For high-performance graphics cards and CPUs, this power supply's 5 CPU & PCI-E slots are more than plenty.PROTECTION MECHANISMSTo make sure the entire system can operate safely and stably at all times, the power supply comes with a number of protection mechanisms to give you the best peace of mind.

Power
Total power650 W
AC input voltage100 - 240 V
Maximum input current (@110V)10 A
Maximum input current (@220V)5 A
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)100 W
Combined power (+12V)648 W
Combined power (+5V)100 W
Combined power (-12V)3.6 W
Combined power (+5Vsb)12.5 W
Max output current (+3.3V)20 A
Max output current (+12V)54 A
Max output current (+5V)20 A
Max output current (-12V)0.3 A
Max output current (+5Vsb)20 A
Efficiency90 %
Power protection featuresOver current,Over power,Over voltage,Short circuit
Ports & interfaces
Motherboard power connector20+4 pin ATX
Number of SATA power connectors6
Peripheral (Molex) power connectors (4-pin)4
EPS power connector (8-pin)N
EPS power connector (4+4 pin)Y
PCI Express power connectors (6+2 pin)4
CPU power connector (4+4 pin)Y
ATX Power connector (24-pin)N
ATX power connector (20+4 pin)Y
Floppy disk drive connectorN
Cabling typeFully-Modular
Performance
80 PLUS certification80 PLUS Bronze
PurposePC
Power supply unit (PSU) form factorATX
Design
Product colourBlack
Cooling typeActive
Fan diameter120 mm
Number of fans1 fan(s)
IlluminationN
On/off switchY
Weight & dimensions
Width150 mm
Depth140 mm
Height86 mm
Logistics data
Harmonized System (HS) code84733020
