GIGABYTE P450B power supply unit 450 W 20+4 pin ATX ATX Black
(0 review)Add your review
€28,09

GIGABYTE P450B, 450 W, 100 - 240 V, 50 - 60 Hz, 8 - 4 A, Active, 103 W

Availability: Arriving Soon
EAN:4719331551612Categories:PowerTags:

80 PLUS BRONZE CERTIFIED80 Plus Bronze certified ensures to deliver 85% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise.Reliable Flat CableP450B provides the best solution for the system builds. The flat cable reduces the clutter and improves the airflow in the case.120mm Silent Hydraulic Bearing (HYB) Fan120mm Silent Hydraulic Bearing fan optimizes the noise reduction and the thermal performance. The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable life time.SINGLE +12V RAILSingle +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.PROTECTIONIn order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.

Power
Total power450 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current8 - 4 A
Power factor0.9
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)103 W
Combined power (+12V)432 W
Combined power (+5V)103 W
Combined power (-12V)3.6 W
Combined power (+5Vsb)15 W
Max output current (+3.3V)18 A
Max output current (+12V)36 A
Max output current (+5V)15 A
Max output current (-12V)0.3 A
Max output current (+5Vsb)3 A
Hold time16 ms
Efficiency85 %
Power protection featuresOver current,Over power,Over voltage,Overheating,Short circuit,Under voltage
Ports & interfaces
Motherboard power connector20+4 pin ATX
Motherboard power cable length550 mm
Number of SATA power connectors6
SATA power cable length500 mm
Peripheral (Molex) power connectors (4-pin)3
Peripheral (Molex) power cable length500 mm
PCI Express power connectors (6+2 pin)2
PCI Express power cable length550 mm
CPU power connector (4+4 pin)Y
CPU power cable length600 mm
ATX power connector (20+4 pin)Y
Floppy drive power connector1
Floppy disk drive connectorY
PCI Express connectorY
Cabling typeNon-Modular
Performance
80 PLUS certification80 PLUS Bronze
PurposePC
Power supply unit (PSU) form factorATX
ATX version2.31
Bearing technologyHDB
Mean time between failures (MTBF)100000 h
Design
Product colourBlack
Cooling typeActive
Fan diameter120 mm
Number of fans1 fan(s)
Fan locationTop
On/off switchY
Weight & dimensions
Width150 mm
Depth140 mm
Height86 mm
Logistics data
Harmonized System (HS) code84733020
